3-1393774-9: DescriptionRF RELAY, SPDT, MOMENTARY, 0.005A (COIL), 24VDC (COIL), 128mW (COIL), 1A (CONTACT), SURFACE MOUNT-STRAIGHT, ROHS COMPLIANT; CategoryMechanical and electronic products relay; File Size113KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

3-1393774-9 Overview

RF RELAY, SPDT, MOMENTARY, 0.005A (COIL), 24VDC (COIL), 128mW (COIL), 1A (CONTACT), SURFACE MOUNT-STRAIGHT, ROHS COMPLIANT

3-1393774-9 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
body width	7.85 mm
body height	8 mm
Body length or diameter	13 mm
Maximum coil current (DC)	0.005 A
Coil power	128 mW
Coil resistance	4500 Ω
Maximum coil voltage (DC)	24 V
Coil/Input Power Type	DC
Maximum contact current (AC)	1 A
Maximum contact current (DC)	1 A
Contact/Output Power Type	AC/DC
Manufacturer's serial number	1393774
Installation features	SURFACE MOUNT-STRAIGHT
method of packing	TUBE
physical size	13mm X 7.85mm X 8mm
Guideline	CSA; UL
Relay action	MOMENTARY
Relay function	SPDT
Relay type	RF RELAY
surface mount	NO
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Relays

Product Feature Selector

> Product Details

V23026D1024B201 Product Details

Communications/Signal PC Board Relays

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

V23026D1024B201

(3-1393774-9)

T E I nternal N umber: 3 - 1 3 9 3 7 7 4 - 9

Product Highlights:

V23026 / P1 Relay Series

DC Actuating System

Input Voltage = 24 VDC

C ontact Arrangement = 1 Form C , SPDT, 1 C /O

C ontact C urrent Rating = 1 Amps.

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Superseded

Search for Replacement Parts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

TELEC OM AND SIGNAL RELAYS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Termination Type = SMT, J-Legs

C omment = Delivered in sticks

Electrical Characteristics:

Actuating System = DC

Input Voltage (VDC ) = 24

C ontact C urrent Rating (Amps.) = 1

C oil Resistance (?)

= 4500

C oil Power, Nominal (mW) = 128

Dielectric Between C oil and C ontacts (V rms) = 1500

Body Related Features:

Series

= V23026 / P1 Relay

Polarized = Yes

Contact Related Features:

Mounting Options = PC Board

Enclosure = Immersion C leanable

FC C Part 68 Isolation

= Yes

Approved Standards = C SA C ertified, UL Recognized

C ontact Base Material = Palladium-Nickel, Gold Overlay, Rhodium

Flash

Approx. Dimensions (L x W x H) (mm [in]) = 13.00 x 7.85 x 8.00

[.512 x .309 x .315]

C ontact Type = Bifurcated

Pin C onfiguration = DIP

Configuration Related Features:

C ontact Arrangement

= 1 Form C , SPDT, 1 C /O

C oil Magnetic System

= Polarized, Monostable

C oil Suppression Diode = Without

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Not suitable for lead free processing

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Other:

Brand = Axicom

Additional Information:

Product Line Information

Additional Product Images:

Product Photo

Schematic

PC B Layout

Wiring Diagram
