MIL-DTL-24308
D-Subminiature
557-283
D-Subminiature
Lightweight Solid EMI/RFI Banding Backshell
557 T 283 M 3 B-06 B
Basic Part No.
Cable Entry Style
T = Top Entry
E = End Entry
S = Side Entry
Basic Part No.
Finish Symbol (Page 3)
B = Band Supplied (600-057), Omit for
None
Entry Size (Table II)
Jackscrew Style
A = Male Socket Head Screw With Clip
B = Male Screw With Clip
H = Hex Head Jackscrew With Clip
Shell Size (Table I)
.30 (7.6) Off-Set
Size 3, 4, 5
.32 (8.1)
Typ
Style T Top
Entry Shell
Sizes
3, 4, & 5
Knurl or Flutes
Mfg Option, Typ
D
Accomodates
Micro Band
600-057
1.00
(25.4)
Style T Top
Entry Shell
Sizes
1&2
1.00
(25.4)
Style S Side
Entry
.250 (6.3)
Typ
Connector Shown for
Reference Only
E
F
.188 (4.8)
Ref.
Style B
Jackscrew
Filister Head
A Typ
C Typ
4-40
Threa
d
Typ
B Typ
Style E
End
Entry
Style A
Jackscrew
Socket
Head
TABLE I: SHELL SIZE & CONNECTOR INTERFACE
Shell
Size
1
2
3
4
5
A Max
1.25 (31.8)
1.58 (40.1)
2.13 (54.1)
2.77 (70.4)
2.68 (68.1)
B
.530 (13.5)
.530 (13.5)
.530 (13.5)
.530 (13.5)
.660 (16.8)
C
±.005 (.1)
.984 (25.0)
1.312 (33.3)
1.852 (47.0)
2.500 (63.5)
2.406 (61.1)
Metric dimensions (mm) are indicated in parentheses.
© 2011 Glenair, Inc.
Entry
D
E
Size
.250 (6.4) .250 (6.4)
04
.312 (7.9) .281 (7.1)
05
.375 (9.5) .312 (7.9)
06
.437 (11.1) .344 (8.7)
07
08* .500 (12.7) .375 (9.5)
* Available in shell size 5 only.
TABLE II: CABLE ENTRY & BACKSHELL DIMS
1.25
1.38
1.38
1.50
1.50
F
(31.8)
(35.1)
(35.1)
(38.1)
(38.1)
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
A-94
