FACTSHEET F-198 SUPPLEMENT
HCMD
.100" IDC CABLE STRIPS
Mates with:
TSW, MTSW, TST, EW,
BST, LCW, ZST, MTLW,
TSM
HCMD, HCMS
HCSD, HCSS
END
ASSEMBLY
TYPE
STRIP
ROW OPTION
NO. PINS
PER ROW
Features:
•
•
•
•
•
•
•
•
Low Profile
Skinny side locks
Dual beam contacts
Single & double row
High temp insulator
Odd lead counts
Customs our specialty
Easy assembly
S
D
= Single
= Double
(Color coded cable
N/A for 31 thru 36
pins/row. See
–G option.)
–05, – 07, – 08, –10,
–12, –13, –15,
–17, –20, –25, –30,
–32, –36
(Call Samtec other sizes)
Specifications:
HCSD, HCSS
Insulator Material:
Black Liquid Crystal Polymer
Flammability Rating:
UL 94V-O
Insulation Resistance:
5000 MΩ
Temperature Range:
-65°C to +80°C
Withstanding Voltage:
1000 VRMS @ 60 Hz
Contact:
Phosphor Bronze
Plating:
10µ" (0,25µm) on contact
area, 150µ" (3,81µm)
Sn on balance over
50µ" (1,27µm) Ni.
Current Rating:
1A
Contact Resistance:
10 mΩ max
Lead Size Range:
.024" (0,61mm) SQ to
.026" (0,66mm) SQ
Lead Insertion Depth:
.185" (4,70mm) to .250"
(6,35mm)
Insertion Force:
6 oz avg (1,67N) average with
.025" (0,64mm) SQ probe
Withdrawal Force:
3 oz avg (0,83N) average with
.025" (0,64mm) SQ probe
Wire:
28 AWG 7/36 stranded
Tinned Copper
HCM
= Male Strip
No. of Positions x .100 (2,54)
+ .180 (4,57)
(3,30)
.130
(5,08)
.200
–S
= Single End
(7,87)
.310
REF
Socket or Male Plug on one end
(0,51)
.020
(3,05)
.120
–D
= Double End
Double
(HCMD)
(2,54)
.100
(0,64)
.025
SQ
TYP
(2,54)
.100
Single
(HCMS)
HCS
= Socket Strip
(3,30)
.130
(5,08)
.200
Specifications:
HCMD, HCMS
Insulator Material:
Black Liquid Crystal Polymer
Flammability Rating:
UL 94V-O
Insulation Resistance:
5000 MΩ
Temperature Range:
-65°C to +80°C
Withstanding Voltage:
1000 VRMS @ 60 Hz
Terminal: Phosphor Bronze
Plating:
150µ" (3,81µm) Sn
over 50µ" (1,27µm) Ni
Current Rating:
1A
Wire:
28 AWG 7/36 stranded
Tinned Copper
Note:
IDC assemblies are
non-standard, non-returnable.
No. of Positions x .100 (2,54)
+ .180 (4,57)
Socket or Male Plug on each end
–T
= Transfer End
(9,53)
.375
REF
(2,54)
.100
(0,76)
.030
SQ. TYP.
Single
(HCSS)
(2,54)
.100
Double
(HCSD)
Male Plug on one end with socket on
other.
Begin part number with HCM.
SAMTEC USA
• Tel: 1-800-SAMTEC-9 or 812-944-6733 • Fax: 812-948-5047
SAMTEC UK
• Tel: 01236 739292 • Fax: 01236 727113
SAMTEC GERMANY
• Tel: +49 (0)8141 / 37 85-0 • Fax: +49 (0)8141 / 37 85-99
SAMTEC FRANCE
• Tel: 33 1 60 24 75 50 • Fax: 33 1 60 24 75 59
SAMTEC ITALY
• Tel: 39-2-38093535 • Fax: 39-2-38093453
SAMTEC ASIA PACIFIC
• Tel: 65-745-5955 • Fax: 65-841-1502
SAMTEC JAPAN
• Tel: 81-424-42-8318 • Fax: 81-424-42-8319
Due to technical progress, all designs, specifications and components are subject to change without notice.
FACTSHEET F-198 SUPPLEMENT
HCSD
.100" IDC CABLE STRIPS
ASSEMBLED
LENGTH
HCMD, HCMS
HCSD, HCSS
OTHER
OPTIONS
01
PLATING
OPTION
NOTCH
POLARIZATION
–“XX”
= Assembled Length
–N
–S
–T
10
µ
" (0,25
µ
m) Gold on contact
area or tail, 150
µ
" (3,81
µ
m)
= Tin on balance
(Standard on HCSS & HCSD.
Leave blank)
= Notch Polarization
(1,27)
.050
02
Assembled Length in
INCHES (±1/8")
2 inches minimum
01
150
µ
" (3,81
µ
m) Tin
= (Standard on HCMS & HCMD.
Leave blank)
(3,81) .150
Required for HCSS and HCSD.
(Not available on HCMS or HCMD, unless
Transfer, then only the socket is polarized.)
– P “XX”
= Position Polarization
– ST “X”
= Stripped & Tinned
Specify Suffix from table. All
dimensions are
±
1
/
16
"
(1,59mm)
. Not
available in 28 positions and higher.
–S “XX”
= Daisy Chain Single
–R
= Reversed
(50,80)
2.00
min.
“XX”
±
1
/
8
" (3,18)
Single Row
Connectors
02
04
01
03
02
04
01
03
Outer Most
(End of
Assembly)
Single
Double
–ST8
–ST4
–ST2
–ST3
1
/ "
8
1
/ "
4
1
/ "
2
3
/ "
8
(3,18)
(6,35)
(12,70)
(9,53)
(101,60)
4.00 minimum
When mating double row connector
with two single row connectors, the
outer most single will be connected
to Conductor #1 and the inside single
to Conductor #2.
6
3
7
–M
= Middle Reversed
Specify “XX” as position. For
Double the same position will be
polarized on both ends. (Not
available on HCM, unless Transfer,
then only the socket is polarized)
– D “XX”
= Daisy Chain, Double
(50,80)
2.00
min.
– B “XX”
= Breakout
Specify “XX” as number of
conducts to be broken out.
“XX”
±
1
/
8
" (3,18)
Double Row
Strips
Requires –SXX, –WXX or –DXX
7
1
“XX”
Outer Most
(End of
Assembly)
–O
= Outside Reversed
6
–G
= Gray Cable
Breakout starts with Number 1
lead indicated by brown wire or
red stripe. Shown on top side.
(127,00)
5.00 max.
(50,80)
2.00 min.
(101,60)
4.00 minimum
4
–W “XX”
= Wiring Reversed
Daisy Chain, Single
Same as –S “XX” except outer strip
connected to conductor #2 and inside
strip connected to conductor #1.
Requires –SXX, –WXX or –DXX
7
Standard cable is color coded. Specify
–G for Gray cable with one red edge.
2
–RW
= Reversed Wiring
#1 wire opposite position #1
5
6
SAMTEC USA
• Tel: 1-800-SAMTEC-9 or 812-944-6733 • Fax: 812-948-5047
SAMTEC UK
• Tel: 01236 739292 • Fax: 01236 727113
SAMTEC GERMANY
• Tel: +49 (0)8141 / 37 85-0 • Fax: +49 (0)8141 / 37 85-99
SAMTEC FRANCE
• Tel: 33 1 60 24 75 50 • Fax: 33 1 60 24 75 59
SAMTEC ITALY
• Tel: 39-2-38093535 • Fax: 39-2-38093453
SAMTEC ASIA PACIFIC
• Tel: 65-745-5955 • Fax: 65-841-1502
SAMTEC JAPAN
• Tel: 81-424-42-8318 • Fax: 81-424-42-8319
Due to technical progress, all designs, specifications and components are subject to change without notice.
