BA782 and BA783
Tuner Diodes
SOD-123
.022 (0.55)
Cathode Band
Pad Layout SOD-123
.152 (3.85)
.140 (3.55)
.112 (2.85)
.100 (2.55)
Top View
0.094 (2.40)
0.055 (1.40)
0.055 (1.40)
.010 (0.25)
min.
.006 (0.15)
max.
.004 (0.1)
max.
.067 (1.70)
.055 (1.40)
.053 (1.35)
max.
Dimensions in inches
and (millimeters)
Mechanical Data
Case:
SOD-123 plastic case
Weight:
approximately 0.01 grams
Cathode Band Color:
Blue
Packaging Codes/Options:
D3/10K per 13” reel (8mm tape)
D4/3K per 7” reel (8mm tape)
Features
• Silicon Epitaxial Planar Diode Switches
• For electric bandswitching in radio and TV tuners
in the frequency range of 50...1000 MHz. The
dynamic forward resistance is constant and very
small over a wide range of frequency and forward
current. The reverse capacitance is also small and
largely independent of the reverse voltage.
• These diodes are also available in SOD-323 case
with the type designations BA782S and BA783S.
Maximum Ratings and Thermal Characteristics
Ratings at 25°C ambient temperature unless otherwise specified.
Parameter
Reverse Voltage
Forward Continuous Current at T
amb
= 25°C
Junction Temperature
Storage Temperature Range
Symbol
V
R
I
F
T
j
T
S
Value
35
100
125
–55 to +125
Unit
V
mA
°C
°C
2/28/00
BA782 and BA783
Tuner Diodes
Electrical Characteristics
Parameter
Forward Voltage
Leakage Current
BA782
BA783
BA782
BA783
Capacitance
Series Inductance across Case
BA782
BA783
Ratings at 25°C ambient temperature unless otherwise specified.
Symbol
V
F
I
R
Test Condition
I
F
= 100 mA
V
R
= 20 V
f = 50...1000 MHz, I
F
= 3 mA
Min
—
—
—
—
—
—
—
—
—
—
Typ
—
—
—
—
—
—
—
—
—
2.5
Max
1
50
0.7
1.2
0.5
0.9
1.5
1.25
1.2
—
Unit
V
nA
Ω
Dynamic Forward Resistance
r
f
f = 50...1000 MHz, I
F
= 10 mA
V
R
= 1 V, f = 1 MHz
C
tot
L
S
V
R
= 3 V, f = 1 MHz
—
pF
nH
Ratings and Characteristic Curves
