SOT-23 Surface Mount Plastic Package
Package Outline, Tape, Reel and Packaging
Information
Continental Device India Limited
Data Sheet
Page 1 of 3
Continental Device India Limited
An ISO/TS16949 and ISO 9001 Certified Company
SOT-23 Formed SMD Package
–0.05
2.50
– 0.02
0.60
–0.025
1.30
–0.02
0.60
SOT-23 Package Reel Information
Reel specifications for Packing (13"/7" reels)
14.4
M AX
ł 100.0– 0.5 / ł 54.5 – 0.5
ł 329.2– 0.5 / 178 – 0.5
7.9 10.9
9.2– 0.5
–0.025
2.90
–0.05
1.90
+0.08
0.40 -0.02
1
cL
3
ł 20.2 M IN
+0.5
0.2
ł 13.0
180
or
330
TRAILER
2
3
3
2.0– 0.5
0.08
–0.02
0.60
PARTING LINE
RO.08
–0.01
0.12
–4"
R0.08
All dimensions in mm
330 / 180 mm Antistatic Coated Plastic Reel
–0.025
0.95
NO TES:
No. of Devices
6
8mm Tape
Size of Reel
330 mm (13")
10,000 Pcs
8mm Tape
Size of Reel
180 mm (7")
3,000 Pcs
0.21
7
–0.05
2.50
5
–3"
–0.04
0.06
1.
2.
3.
4.
5.
The bandolier of 330 mm reel contains at least 10,000 devices.
The bandolier of 180 mm reel contains at least 3,000 devices.
No m ore than 0.5% missing devices / reel. 50 empty com partments for 330 mm reel.
15 empty compartments for 180 mm reel.
Three consecutive empty places might be found provided this gap is followed by 6
consecutive devices.
The carrier tape (leader) starts with at least 75 empty positions (equivalent to 330
mm). In order to fix the carrier tape a self adhesive tape of 20 to 50 mm is applied. At
the end of the bandolier at least 40 em pty positions (equivalent to 160 mm) are there.
Tape Specification for SOT-23 Surface Mount Device
– 0.1
4.0
– 0.05
– 0.1
2.0
4.0
– 0.1
1.75
+0.3 – 0.05
- 0.1 3.5
8.0
5.75
M AX
– 0.05
– 0.05
1.55
– 0.10
2.77
– 0.1
1.22
1.6
M AX
1.0
– 0.10
3.15
Direction of Unreeling
All dimensions in mm
Continental Device India Limited
Data Sheet
Page 2 of 3
FIXING
TAPE
– 0.02
0.60
1.30
7
0.08
DETAIL X
LEADER
– 0.02
0.60
Packing Detail
PACKAGE
Details
SOT-23 T&R
3K/reel
10K/reel
STANDARD PACK
Net Weight/Qty
136 gm/3K pcs
415 gm/10K pcs
Size
3" x 7.5" x 7.5"
9" x 9" x 9"
13" x 13" x 0.5"
INNER CARTON BOX
Qty
12.0K
51.0K
10.0K
Size
17" x 15" x 13.5"
19" x 19" x 19"
17" x 15" x 13.5"
OUTER CARTON BOX
Qty
192.0K
408.0K
300.0K
Gr Wt
12 kgs
28 kgs
16 kgs
Customer Notes
Disclaimer
