BY539-1500 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BY539-1500

BY539-1500: DescriptionDIODE 10 A, 1500 V, SILICON, RECTIFIER DIODE, TO-220AC, Rectifier Diode; CategoryDiscrete semiconductor diode; File Size64KB，1 Pages; ManufacturerNXP; Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

BY539-1500 Overview

DIODE 10 A, 1500 V, SILICON, RECTIFIER DIODE, TO-220AC, Rectifier Diode

BY539-1500 Parametric

Parameter Name	Attribute value
package instruction	R-PSFM-T2
Reach Compliance Code	unknown
ECCN code	EAR99
application	POWER
Shell connection	CATHODE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JEDEC-95 code	TO-220AC
JESD-30 code	R-PSFM-T2
Maximum non-repetitive peak forward current	60 A
Phase	1
Number of terminals	2
Maximum output current	10 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	1500 V
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Base Number Matches	1

Preview

Download Datasheet

View All

BY539-1500 Related Products

	BY539-1500	BY646	BY647	BY617	BY706	BY658	BY657	BY705	BY648
Description	DIODE 10 A, 1500 V, SILICON, RECTIFIER DIODE, TO-220AC, Rectifier Diode	DIODE 0.005 A, 8000 V, SILICON, SIGNAL DIODE, Signal Diode	DIODE 0.005 A, 10000 V, SILICON, SIGNAL DIODE, Signal Diode	DIODE 0.004 A, 9000 V, SILICON, SIGNAL DIODE, Signal Diode	DIODE 0.02 A, 6000 V, SILICON, SIGNAL DIODE, Signal Diode	DIODE 0.005 A, 12000 V, SILICON, SIGNAL DIODE, Signal Diode	DIODE 0.005 A, 10000 V, SILICON, SIGNAL DIODE, Signal Diode	0.02A, 5000V, SILICON, SIGNAL DIODE	DIODE 0.005 A, 12000 V, SILICON, SIGNAL DIODE, Signal Diode
Reach Compliance Code	unknown	unknown	unknown	compliant	compliant	unknown	unknown	compliant	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Shell connection	CATHODE	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED
Diode component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
JESD-30 code	R-PSFM-T2	O-LALF-W2	O-LALF-W2	O-LALF-W2	O-LALF-W2	O-LALF-W2	O-LALF-W2	O-LALF-W2	O-LALF-W2
Number of terminals	2	2	2	2	2	2	2	2	2
Maximum output current	10 A	0.005 A	0.005 A	0.004 A	0.02 A	0.005 A	0.005 A	0.02 A	0.005 A
Package body material	PLASTIC/EPOXY	GLASS	GLASS	GLASS	GLASS	GLASS	GLASS	GLASS	GLASS
Package shape	RECTANGULAR	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND
Package form	FLANGE MOUNT	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	1500 V	8000 V	10000 V	9000 V	6000 V	12000 V	10000 V	5000 V	12000 V
surface mount	NO	NO	NO	NO	NO	NO	NO	NO	NO
Terminal form	THROUGH-HOLE	WIRE	WIRE	WIRE	WIRE	WIRE	WIRE	WIRE	WIRE
Terminal location	SINGLE	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL
package instruction	R-PSFM-T2	O-LALF-W2	O-LALF-W2	-	-	O-LALF-W2	O-LALF-W2	-	O-LALF-W2
Base Number Matches	1	1	1	1	1	-	-	-	-
Configuration	-	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Number of components	-	1	1	1	1	1	1	1	1
