RECTRON
SEMICONDUCTOR
TECHNICAL SPECIFICATION
HVM5
THRU
HVM16
HIGH VOLTAGE ASSEMBLIED RECTIFIER
VOLTAGE RANGE 5000 to 16000 Volts CURRENT 0.35 Amperes
FEATURES
*
*
*
*
*
*
Low cost
Low leakage
Isolated case
Surge overload rating - 50 amperes peak
Mounting position: Any
Low forward voltage drop
HVM
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
o
MAXIMUM RATINGS
(At T
A
= 25
o
C unless otherwise noted)
RATINGS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current at T
A
= 50 C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Operating and Storage Temperature Range
o
SYMBOL
V
RRM
V
RMS
V
DC
I
O
HVM5
5
3.5
5
HVM8
8
5.6
8
HVM10
10
7.0
10
HVM12
12
8.4
12
350
HVM14
14
9.8
14
HVM15
15
10.5
15
HVM16
16
11.2
16
UNITS
K Volts
K Volts
K Volts
mAmps
I
FSM
T
J,
T
STG
50
-20 to + 135
Amps
0
C
ELECTRICAL CHARACTERISTICS
(At T
A
= 25 C unless otherwise noted)
CHARACTERISTICS
Maximum Instantaneous Forward Voltage at 0.35A DC
Maximum DC Reverse Current
at Rated DC Blocking Voltage
NOTES:1. Enough heat sink must be considered in application.
2. Operating and Storage Temperature : -20
o
C to +135
o
C
3. Suffix “ L “ for Wire type.
SYMBOL
V
F
I
R
HVM5
8.0
HVM8
HVM10
14.0
5.0
HVM12
HVM14
HVM15
14.0
HVM16
UNITS
Volts
uAmps
1998-8
