Bulletin PD-20555 rev. B 02/03
30L30CT
30L30CTS
30L30CT-1
SCHOTTKY RECTIFIER
30 Amp
Major Ratings and Characteristics
Characteristics
I
F(AV)
Rectangular
waveform
V
RRM
V
F
T
J
@ 15 Apk, T
J
= 125°C
(Per Leg)
range
- 55 to 150
°C
30
0.37
V
V
Description/ Features
Units
A
This center tap Schottky rectifier has been optimized for very
low forward voltage drop, with moderate leakage. The
proprietary barrier technology allows for reliable operation
up to 150° C junction temperature. Typical applications are
in switching power supplies, converters, free-wheeling
diodes, and reverse battery protection.
150° C T
J
operation
Center tap configuration
Very low forward voltage drop
High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
High frequency operation
Guard ring for enhanced ruggedness and long term
reliability
Values
2 x 15
Case Styles
30L30CT
30L30CTS
30L30CT -1
Base
Common
Cathode
2
Base
Common
Cathode
2
Base
Common
Cathode
2
1
Anode
2
Common
Cathode
3
1
Anode
Anode
2
Common
Cathode
3
1
Anode
Anode
2
Common
Cathode
3
Anode
TO-220
www.irf.com
D
2
PAK
TO-262
1
30L30CT, 30L30CTS, 30L30CT-1
Bulletin PD-20555 rev. B 02/03
Voltage Ratings
Parameters
V
R
Max. DC Reverse Voltage (V)
30L30CT
30L30CTS
30L30CT-1
30
V
RWM
Max. Working Peak Reverse Voltage (V)
Absolute Maximum Ratings
Parameters
I
F(AV)
Max. Average Forward
Current
I
FSM
E
AS
I
AR
Surge Current
Non-Repetitive Avalanche Energy
(Per Leg)
Repetitive Avalanche Current
(Per Leg)
2
A
Current decaying linearly to zero in 1 µsec
Frequency limited by T
J
max. V
A
= 1.5 x V
R
typical
Per Device
Per Leg
Values
30
15
1450
220
15
Units Conditions
A
A
mJ
50% duty cycle @ T
C
= 140°C, rectangular wave form
Following any rated
load condition and
10ms Sine or 6ms Rect. pulse
with rated V
RRM
applied
Max. Peak One Cycle Non-Repetitive
5µs Sine or 3µs Rect. pulse
T
J
= 25 °C, I
AS
= 2 Amps, L = 7.5 mH
Electrical Specifications
Parameters
V
FM
Max. Forward Voltage Drop
(Per Leg)
(1)
Values
0.46
0.57
0.37
0.50
1.50
350
1500
8.0
10000
Units Conditions
V
V
V
V
mA
mA
pF
nH
V/µs
@ 15A
@ 30A
@ 15A
@ 30A
T
J
= 25 °C
T
J
= 125 °C
T
J
= 25 °C
T
J
= 125 °C
V
R
= rated V
R
I
RM
C
T
L
S
Max. Reverse Leakage Current
(Per Leg)
Max. Junction Capacitance(Per Leg)
Typical Series Inductance (Per Leg)
V
R
= 5V
DC
(test signal range 100Khz to 1Mhz) 25°C
Measured lead to lead 5mm from package body
(Rated V
R
)
dv/dt Max. Voltage Rate of Change
(1) Pulse Width < 300µs, Duty Cycle <2%
Thermal-Mechanical Specifications
Parameters
T
J
T
stg
Max. Junction Temperature Range
Max. Storage Temperature Range
Values
-55 to 150
-55 to 150
1.5
0.8
2 (0.07)
Min.
Max.
6 (5)
12 (10)
Units Conditions
°C
°C
°C/W DC operation
°C/W DC operation
g (oz.)
Kg-cm
(Ibf-in)
R
thJC
Max. Thermal Resistance Junction
to Case (Per Leg)
R
thJC
Max. Thermal Resistance Junction
to Case (Per Package)
wt
T
Approximate Weight
Mounting Torque
2
www.irf.com
30L30CT, 30L30CTS, 30L30CT-1
Bulletin PD-20555 rev. B 02/03
000
(mA)
000
T = 150˚C
J
100
10
1
0.1
0.01
0
5
10
15
20
125˚C
100˚C
75˚C
50˚C
25˚C
Instantaneous Forward Current - I
F
(A)
100
Reverse Current - I
R
25
30
Reverse Voltage - V
R
(V)
Fig. 2 - Typical Values of Reverse Current
Vs. Reverse Voltage
10000
(pF)
T = 150˚C
T = 25˚C
J
J
T = 25˚C
Junction Capacitance - C
T = 125˚C
T
10
J
J
1000
1
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
Forward Voltage Drop - V
FM
(V)
Fig. 1 - Maximum Forward Voltage Drop Characteristics
100
0
5
10
15
20
25
30
35
Reverse Voltage - V
R
(V)
Fig. 3 - Typical Junction Capacitance
Vs. Reverse Voltage
10
(°C/W)
thJC
Thermal Impedance Z
1
D = 0.75
D = 0.50
D = 0.33
D = 0.25
D = 0.20
P
DM
t1
t2
Single Pulse
(Thermal Resistance)
Notes:
1. Duty factor D = t1/ t 2
2. Peak Tj = Pdmx ZthJC + Tc
0.1
.01
0.00001
0.0001
0.001
0.01
0.1
1
10
t
1
, Rectangular Pulse Duration (Seconds)
Fig. 4 - Max. Thermal Impedance Z
thJC
Characteristics
www.irf.com
3
30L30CT, 30L30CTS, 30L30CT-1
Bulletin PD-20555 rev. B 02/03
50
Allowable Case Temperature (°C)
Average Power Loss (Watts)
10
8
6
4
2
0
0
5
10
15
20
F(AV)
45
DC
RMS Limit
DC
DC = 0.20
DC = 0.25
DC = 0.33
DC = 0.50
DC = 0.75
40
35
Square wave (D = 0.50)
see note (2)
30
0
5
10
15
20
F(AV)
25
(A)
25
(A)
Average Forward Current - I
Average Forward Current - I
Fig. 5 - Max. Allowable Case Temperature
Vs. Average Forward Current
Fig. 6 - Forward Power Loss
Characteristics
(A)
FSM
10000
At Any Rated Load Condition
And With Rated Vrrm Applied
Following Surge
Non-Repetitive Surge Current - I
1000
100
10
100
1000
p
10000
(microsec)
Square Wave Pulse Duration - t
Fig. 7 - Max. Non-Repetitive Surge Current (Per Leg)
(2)
Formula used: T
C
= T
J
- Pd x R
thJC
;
Pd = Forward Power Loss = I
F(AV)
x V
FM
@ (I
F(AV)
/
D) (see Fig. 6)
4
www.irf.com
30L30CT, 30L30CTS, 30L30CT-1
Bulletin PD-20555 rev. B 02/03
Outline Table
10.54 (0.41)
MAX.
3.78 (0.15)
3.54 (0.14)
15.24 (0.60)
14.84 (0.58)
1 2 3
14.09 (0.55)
13.47 (0.53)
3.96 (0.16)
3.55 (0.14)
2.04 (0.080) MAX.
1.40 (0.05)
1.15 (0.04)
0.94 (0.04)
0.69 (0.03)
2.89 (0.11)
2.64 (0.10)
1
2
Common
Cathode
3
1.32 (0.05)
DIA.
6.48 (0.25)
6.23 (0.24)
2°
Base
Common
Cathode
2
1.22 (0.05)
2.92 (0.11)
2.54 (0.10)
TERM 2
0.10 (0.004)
Anode
Anode
1 2 3
4.57 (0.18)
4.32 (0.17)
0.61 (0.02) MAX.
5.08 (0.20) REF.
Conform to JEDEC outline TO-220AB
Dimensions in millimeters and (inches)
10.16 (0.40)
REF.
4.69 (0.18)
4.20 (0.16)
1.32 (0.05)
6.47 (0.25)
15.49 (0.61)
1.22 (0.05)
93°
6.18 (0.24)
14.73 (0.58)
2.61 (0.10)
2.32 (0.09)
8.89 (0.35)
5.28 (0.21)
4.78 (0.19)
0.55 (0.02)
0.46 (0.02)
3X
Base
Common
Cathode
2
1.40 (0.055)
REF.
0.93 (0.37)
0.69 (0.27)
1.14 (0.045)
2X
MINIMUM RECOMMENDED FOOTPRINT
11.43 (0.45)
1
3
4.57 (0.18)
4.32 (0.17)
2
0.61 (0.02) MAX.
1
2
Common
Cathode
3
8.89 (0.35)
17.78 (0.70)
5.08 (0.20) REF.
3.81 (0.15)
2.08 (0.08)
2X
Anode
Anode
2.54 (0.10)
2X
Conform to JEDEC outline D Pak (SMD-220)
Dimensions in millimeters and (inches)
2
www.irf.com
5
