556-3006-324F Overview

Single Color LED

556-3006-324F Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	DIALIGHT
Reach Compliance Code	compliant
Optoelectronic device types	SINGLE COLOR LED
Base Number Matches	1

Preview

Download Datasheet

View All

Application:

The 556 Series LED Panel Mount Indicators incorporate both InGaN

and AlInGaP technologies to offer maximum light output. This is a

highly durable package, designed to withstand outdoor applica-

tions susceptible to rain, dust and sunlight. In addition, the Class I,

Division 2 rating allows for use in hazardous environments common

to the oil and gas, mining, and chemical industries.

• Instrument panels

• Mining application

• Safety applications

• Oil Refineries

• UL 508 panel applications

• Transportation - rail, bus, airline

• Agricultural controls

• Petrochemical applications

• Power generators

• Pump system controllers

• Environmental Monitoring Equipment specifications

556 Series

Class I, Div. 2

Panel Mount Indicators

FLAT LENS

DOMED LENS

...and many more!

Mechanical Information

Mounting Hole Size:

Max Panel Thickness:

Mounting Torque:

Electrical specifications

Operating Voltage:

12 to 125VDC and 125, 230VAC

-30°C to +85°C

-40°C to +100°C

6-32 Screw Terminals

1” (25.4 mm)

Flat; .600” (15.24 mm);

Dome: .187” (4.75 mm)

40 in-lbs torque

.32

(8.13)

.87

(22.09)

1.50

(38.1)

1.76

(44.7)

1.915 MAX

(48.64)

1.12

(28.5)

.280

(7.1)

.430

(10.39)

.810

(20.6)

1.05

(26.9)

1.22

(31.0)

Operating Temp:

Storage Temp:

Electrical connection

Construction

Housing:

Lens Material:

Terminals:

Nickel Plated Brass

Transparent Polycarbonate (UL 94V-0)

Brass – Hot solder dip per Mil-F-14072D,

M258, Type II

Phosphor Bronze – White Nickel Plated

Brass – White Nickel Plated

Dimensions in inches [mm]

Polarity marking near positive supply terminal

Lock washer:

Nut:

Certifications & Ratings

•

UL1598

•

NEMA 4x IP66

•

RoHS Compliant

•

IK07

Features and Benefits

•

Rated for use in Class I, Div. 2 hazardous locations

•

UL recognized – File #E156890

•

Watertight seal from front of panel - NEMA 4X IP66

•

Tamperproof / Designed for high durability

•

Long life, lasting up to 100k hours

•

Uniform illumination - multi-LED construction

•

Low profile flat lens or wide angle domed lens

•

IP66 from front of panel

www.dialight.com

•

Dialight HQ (P) 732-919-3119
