LV1017: DescriptionBi-CMOS IC Passive Decoder for Dolby Surround Systems; CategoryOther integrated circuit (IC) Consumption circuit; File Size323KB，3 Pages; ManufacturerSANYO; Websitehttp://www.semic.sanyo.co.jp/english/index-e.html

Download Datasheet Parametric View All

LV1017 Overview

Bi-CMOS IC Passive Decoder for Dolby Surround Systems

LV1017 Parametric

Parameter Name	Attribute value
Maker	SANYO
Parts packaging code	DIP
package instruction	SDIP, SDIP36,.4
Contacts	36
Reach Compliance Code	unknow
Commercial integrated circuit types	CONSUMER CIRCUIT
JESD-30 code	R-PDIP-T36
length	32.4 mm
Number of functions	1
Number of terminals	36
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SDIP
Encapsulate equivalent code	SDIP36,.4
Package shape	RECTANGULAR
Package form	IN-LINE, SHRINK PITCH
power supply	9 V
Certification status	Not Qualified
Maximum seat height	3.95 mm
Maximum supply voltage (Vsup)	10 V
Minimum supply voltage (Vsup)	8 V
surface mount	NO
technology	BICMOS
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal pitch	1.778 mm
Terminal location	DUAL
width	10.16 mm

Preview

Download Datasheet

View All

Ordering number : ENN*7929

Bi-CMOS IC

LV1017

Overview

Features

Passive Decoder for

Dolby Surround Systems

The LV1017 is a passive decoder for Dolby surround systems.

•

Original A/D, D/A converter

•

Wide dynamic range

•

Virtual surround function

•

Rear stereo, pseudo-multi-tap function

•

Surround trim (Ls, Rs) external input

•

Built-in Lch, Rch, Lsch, Rsch output switching function

•

Reduced external component count

Specifications

Maximum Ratings

at Ta = 25°C

Parameter

Maximum power supply voltage

Allowable power dissipation

Operating temperature

Storage temperature

Symbol

VCC max

Pd max

Topr

Tstg

Ta

≤

70°C

Conditions

Ratings

12

450

-20 to +70

-40 to +125

Unit

V

mW

°C

Operating Conditions

at Ta = 25°C

Parameter

Recommended operating voltage

Allowable operating voltage range 1

Allowable operating voltage range 2

Dolby level

Input "H" level voltage

Input "L" level voltage

Symbol

VCC

VCC range1

VCC range2

VO Dolby

VIH

VIL

When Dolby surround is ON

When Dolby Pro Logic surround is ON

Conditions

Ratings

9

8 to 10

8.5 to 10

300

3.5 to 5.5

0 to 1.0

Unit

V

mVrms

V

52504 JO IM No.7929-1/3
