Part Number

Search

MM3S0520

Description
0.5 A, SILICON, SIGNAL DIODE
CategoryDiscrete semiconductor    diode
File Size644KB,3 Pages
ManufacturerMicrosemi
Websitehttps://www.microsemi.com
Download Datasheet Parametric Compare View All

MM3S0520 Overview

0.5 A, SILICON, SIGNAL DIODE

MM3S0520 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerMicrosemi
package instructionPLASTIC PACKAGE-2
Contacts2
Reach Compliance Codeunknow
ECCN codeEAR99
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
JESD-30 codeR-PDSO-G2
JESD-609 codee0
Number of components1
Number of terminals2
Maximum output current0.5 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
surface mountYES
technologySCHOTTKY
Terminal surfaceTIN LEAD
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Base Number Matches1
MM3S0520 thru MM3S05100
SCOTTSDALE DIVISION
0.5 Amp Schottky Rectifier
20 –100 Volts
P
RODUCT
P
REVIEW
DESCRIPTION
These Schottky rectifiers are for general-purpose high speed switching
applications particularly where a small package is required. This thermally
efficient design permits an average forward current rating of 0.5 amps in a
small SOD-323 package when adequate PC board mounting is provided.
KEY FEATURES
Schottky Barrier Rectifier
Guard Ring Protection
Low Forward Voltage
Reverse Energy Tested
High Current Capability
Extremely Low Thermal
Resistance
APPLICATIONS
High-Speed Switching
Surface Mount
W W W.
Microsemi
.COM
IMPORTANT:
For the most current data, consult
MICROSEMI’s
website:
http://www.microsemi.com
MAXIMUM RATINGS
Operating Temperature: -65°C to +125°C
Storage Temperature: -65°C to +150°C
Maximum Thermal Resistance: 60°C/W Junction To Lead
Forward Surge Current (I
FSM):
20 Amps at 8.3 ms, half-sine
wave
Average Forward Current (I
O
): 0.5 Amps at 30°C
SOD-323
ELECTRICAL CHARACTERISTICS @ 25°C Unless otherwise specified
Repetitive
Peak
Recovery
Voltage
V
RW M
Volts
MAX
MM3S0520
MM3S0530
MM3S0540
MM3S0560
MM3S0580
MM3S05100
* Pulse test at 300 µs
20
30
40
60
80
100
Forward
Voltage
*
@ 0.5A
V
F
Volts
MAX
0.45
0.55
0.55
0.70
0.85
0.85
Leakage
Current
@
V
RW M
100°C
I
R
mA
MAX
20
20
20
20
20
20
Part
Number
Leakage
Current
@
V
RW M
I
R
mA
MAX
0.5
0.5
0.5
0.5
0.5
0.5
Capacitance
@
V
R
= 4 V,
1 MHz
C
J
pF
TYP
30
30
30
30
30
30
0.074”
MM3S0520 – MM3S05100
0.027”
0.022”
Copyright
2001
MM3S0520-05100.PDF 02-15 2002
Microsemi
Scottsdale Division
8700 E. Thomas Rd. PO Box 1390, Scottsdale, AZ 85252 USA, (480) 941-6300, Fax: (480) 947-1503
Page 1
