B1063 Overview

Telecom Transformer

B1063 Parametric

Parameter Name	Attribute value
Maker	Pulse Electronics
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	APPROVED FOR USE WITH INFINEON PEB22622, PEF22623 AND PEF24622 SHDSL CHIPSET
Maximum DC unbalanced current	60 mA
high	12.32 mm
length	13.46 mm
Manufacturer's serial number	B1063
Installation features	SURFACE MOUNT
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
method of packing	TUBE
physical size	13.46mm X 13.11mm X 12.32mm
surface mount	YES
Transformer type	TELECOM TRANSFORMER
width	13.11 mm
Base Number Matches	1

Preview

Download Datasheet

View All

SHDSL LINE TRANSFORMERS

Approved for use with Infineon’s PEB22622,

PEF22623 and PEF24622 SHDSL chipsets

Excellent THD performance

Designed to meet UL 1950 and EN 60950

requirements for supplementary insulation

and 250 V working voltage

Electrical Specifications @ 25°C — Operating Temperature -40°C to +85°C

Part

Number

B1063

B1093

Mounting

SMT

THT

Turns Ratio

(line - chip)

3.2:1

OCL

Primary

(mH ±10%)

3.0

Leakage Inductance

(µH MAX)

DC Current

Capability

(mA)

Additional Specifications

Part

Number

B1063

B1093

Turns Ratio

(line - sense)

3.2:1

THD

(Linearity)

-75

dB MIN @ 3 KHz

DC Resistance

Primary (1-5, 2-4 short)

Secondary (9-7)

DCR Sense Winding

(10-6)

Isolation Voltage

(Vrms)

2000

4.0

MAX

0.8

MAX

5.0

MAX

Transformers are shipped in tubes unless tape and reel is specified. Please add the suffix

“T”

(i.e. B1063T) for tape and reel orders.

Mechanicals

B1063

10 X .028

± .002

0,71

± 0,05

.695

17,65 MAX

.530

13,46

MAX

.394

10,00

MAX

10 X .051

± .002

1,30

± 0,05

.605

15,37

.100

2,54

.394

10,00

.098

2,50

.020

0,51

B1093

Date Code

Country of Mfg.

Date Code

Country of Mfg.

B1063

.098

2,50

.526

13,36MAX

.516

13,11MAX

.485

12,32

MAX

.185 MAX

4,70

.394

10,00

.535

13,59MAX

10 X

.005/0,13

10 SURFACES

.098

2,50

.394

10,00

.547

13,89MAX

Schematic

Primary (Line)

3.2:1:1

Secondary (Chip)

Sense Winding

HONG KONG

(Great China)

19/F, China United Plaza

1008 Tai Nan West Street

Cheung Sha Wan, Kowloon

Hong Kong, China

TEL: 852 2788 6588

FAX: 852 2776 1055

B1063

B1093

Weight

......................6.2 grams .............6.2 grams

Tape & Reel.................150/reel.......................N/A

Tray/Tube

......................60/tray .................60/tube

Dimensions:

Inches

Unless otherwise specified, all tolerances are ± .010

0,25

For More Information :

UNITED STATES

(Worldwide)

12220 World Trade Drive

San Diego, CA 92128

U.S.A.

http://www.pulseeng.com

TEL: 858 674 8100

FAX: 858 674 8262

UNITED KINGDOM

(Northern Europe)

1 & 2 Huxley Road

The Surrey Research Park

Guildford, Surrey GU2 5RE

United Kingdom

TEL: 44 1483 401700

FAX: 44 1483 401701

FRANCE

SINGAPORE

(Southern Europe) (Southern Asia)

Zone Industrielle

F-39270

Orgelet

France

TEL: 33 3 84 35 04 04

FAX: 33 3 84 25 46 41

150 Kampong Ampat

#07-01/02

KA Centre

Singapore 368324

TEL: 65 287 8998

FAX: 65 280 0080

TAIWAN, R.O.C.

(Northern Asia)

3F-4, No. 81, Sec. 1

HsinTai Wu Road

Hsi-Chih, Taipei Hsien

Taiwan, R.O.C.

Tel: 886 2 2698 0228

FAX: 886 2 2698 0948

DISTRIBUTOR

Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product

names mentioned herein may be trademarks or registered trademarks of their respective owners.

PRELIMINARY B993.P (12/01)
