50 µm multimode (OM3), MTP
®
(pinned) to SC Duplex, 96 F, 36-in
legs on both ends, pulling grip one side, 100 ft
Plug & Play™ Universal Hybrid Extender
Trunk
Plug and Play™ Universal System Hybrid Connector
trunks are terminated with MTP
®
connectors on one
end of the trunk and SC connectors on the other end for
applications requiring one end of the trunk to connect di-
rectly into system equipment or patch panels. Both Plug
and Play Universal System trunks and extender trunks
are available in hybrid connector options.
Features and Benefits
Factory-terminated solutions
Provide consistent quality, ensure system performance,
and reduce installation time
Universal-wired modular system components
Enable moves, adds and changes without polarity con-
cerns; provide a simple migration path between 2-fiber
and parallel optics applications
Low insertion loss performance
Allows for more connections in a link when deploying a
TIA-942-compliant system
Corning
®
ClearCurve
®
50 μm optical fiber
Offers enhanced bend performance, allowing tighter
cable routing without negatively impacting system perfor-
mance
100G ready performance
Ensures product will meet the requirements of 100G
Ethernet applications
Maximum skew of 0.75 ns
Product is assured to work in parallel optic applications
for Ethernet, Fiber Channel and InfiniBand
Protective pulling grip
Protects one end of the assembly during installation
Part Number: A935796TPNBLZ100F
Standards
Design and Test Criteria
NFPA 262 (for plenum, riser
and general building appli-
cations)
Product Specification A935796TPNBLZ100F_NAFTA_AEN
Page 1 | Revision date 2016-02-12
50 µm multimode (OM3), MTP
®
(pinned) to SC Duplex, 96 F, 36-in
legs on both ends, pulling grip one side, 100 ft
Plug & Play™ Universal Hybrid Extender
Trunk
Specifications
General Specifications
Application
Cable Assembly Type
Cable Type
Number of Pulling Grips
Fiber Category
Data Center LAN/SAN
Plug & Play™ Extender Trunk
Indoor; ANSI/ICEA S-83-596
1
50 µm MM (OM3)
Temperature Range
Operation
-10 °C to 60 °C (14 °F to 140 °F)
Design - Connector A
Connector Type
Ferrule Material
MTP
®
(pinned)
Composite
Optical Specifications - Connector A
Insertion Loss, Max.
Reflectance
0.35 dB
< -20 dB
Design - Connector B
Connector Type
Ferrule Material
SC duplex
Ceramic
Optical Specifications - Connector B
Insertion Loss, Max.
Reflectance
0.15 dB
< -20 dB
Cable Design
Fiber Count
Outer Jacket Color
Polarity
Product Specification A935796TPNBLZ100F_NAFTA_AEN
Page 2 | Revision date 2016-02-12
96
Aqua
Universal; TIA-568 Type-C
50 µm multimode (OM3), MTP
®
(pinned) to SC Duplex, 96 F, 36-in
legs on both ends, pulling grip one side, 100 ft
Plug & Play™ Universal Hybrid Extender
Trunk
Mechanical Characteristics Cable
Nominal Outer Diameter
Min. Bend Radius Installation
Min. Bend Radius Operation
Max. Tensile Strength for Installation
Weight
11.9 mm ± 0.3 mm (0.47 in (± 0.01 in))
178.5 mm (7.0 in)
59.5 mm (2.3 in)
660 N
109 kg/km (240 lb/1000 ft)
Optical Characteristics (cabled)
Fiber Compliance
Wavelengths
Maximum Attenuation
Min. Overfilled Launch (OFL) Bandwidth
Minimum Effective Modal Bandwidth (EMB)
Serial 1 Gigabit Ethernet
Serial 10 Gigabit Ethernet
Induced Attenuation @ 7.5 mm Radius
Skew
IEC 60793-2-10 for A1a class 50/125 multimode fibers; TIA/
EIA 492AAAC-A (OM3); ITU-T Recommendation G.651; ISO/
IEC 11801 Ed.2.2 Grade OM3
850 nm / 1300 nm
2.8 dB/km / 1.0 dB/km
1500 MHz*km / 500 MHz*km
2000 MHz*km / -
1000 m / 600 m
300 m / -
< 0.2 dB (2 turns; 7.5 mm radius; 850 nm)
< 0.75 ns @ 300 m
Furcation - Connector A
Leg Length
Leg Color
Leg Diameter
Furcation Type - A
914 mm [Shortest Leg = (+76 mm/-0 mm), Others Vary] (36 in
[Shortest Leg = (+3 in/-0 in), Others Vary])
Aqua
2.0 mm
Heat-shrink for U-Clip
Furcation - Connector B
Leg Length
Leg Color
Leg Diameter
Furcation Type - B
914 mm [Shortest Leg = (+76 mm/-0 mm), Others Vary] (36 in
[Shortest Leg = (+3 in/-0 in), Others Vary])
Aqua
2.0 mm
PnP Size 2
Product Specification A935796TPNBLZ100F_NAFTA_AEN
Page 3 | Revision date 2016-02-12
50 µm multimode (OM3), MTP
®
(pinned) to SC Duplex, 96 F, 36-in
legs on both ends, pulling grip one side, 100 ft
Plug & Play™ Universal Hybrid Extender
Trunk
Pulling Grip - Connector A
Pulling Grip - Connector A
Pulling Grip Outer Diameter
Min. Duct Size Diameter
Tensile Strength
Yes
26 mm (1.0 in)
38.1 mm (1.5 in)
1320 N (300 lb)
Pulling Grip - Connector B
Pulling Grip - Connector B
No
Chemical Characteristics
RoHS
Free of hazardous substances according to RoHS 2002/95/
EG
Fiber Specifications
Optical Characteristics (cabled)
Fiber Type
Fiber Core Diameter
Fiber Category
Fiber Code
Performance Option Code
Wavelengths
Maximum Attenuation
Min. Overfilled Launch (OFL) Bandwidth
Minimum Effective Modal Bandwidth (EMB)
Serial 1 Gigabit Ethernet
Serial 10 Gigabit Ethernet
Induced Attenuation @ 7.5 mm Radius
Multimode
50 µm
OM3
T
80
850 nm / 1300 nm
2.8 dB/km / 1.0 dB/km
1500 MHz*km / 500 MHz*km
2000 MHz*km / -
1000 m / 600 m
300 m / -
< 0.2 dB (2 turns, 850 nm)
*
Single-mode (OS2) fiber is ITU-T G.652.D compliant.
*
50 µm multimode fiber (OM3/OM4) meets 0.75 ns optical skew when used in all Corning Plug & Play™/EDGE™ systems solutions.
*
OM3/OM4 Multimode fiber minimum effective modal bandwidth assumes 1.0 dB maximum total connector/splice loss.
Notes:
1)
Improved attenuation and bandwidth options available.
2)
Bend-insensitive single-mode fibers available on request.
3)
Contact a Corning Customer Care Representative for additional information.
Product Specification A935796TPNBLZ100F_NAFTA_AEN
Page 4 | Revision date 2016-02-12
50 µm multimode (OM3), MTP
®
(pinned) to SC Duplex, 96 F, 36-in
legs on both ends, pulling grip one side, 100 ft
Plug & Play™ Universal Hybrid Extender
Trunk
Ordering Information
Part Number
Product Description
EAN Code
Length
Weight
A935796TPNBLZ100F
Plug & Play™ Universal Hybrid Extender Trunk, 50 µm multi-
mode (OM3), MTP
®
(pinned) to SC Duplex, 96 F, 36-in legs on
both ends, pulling grip one side, 100 ft
4056418677552
100 ft (+10.5 ft/-0 ft) (30 m (+3.20 m/-0 m))
24.0 lb (10.9 kg)
Shipping Information
Units per Delivery
1/1
Corning Optical Communications LLC • PO Box 489 • Hickory, NC 28603-0489 USA
800-743-2675 • FAX: 828-325-5060 • International: +1-828-901-5000 • www.corning.com/opcomm
A complete listing of the trademarks of Corning Optical Communications is available at www.corning.com/opcomm/trademarks.
All other trademarks are the properties of their respective owners. Corning Optical Communications is ISO 9001 certified.
© 2016 Corning Optical Communications. All rights reserved.
Product Specification A935796TPNBLZ100F_NAFTA_AEN
Page 5 | Revision date 2016-02-12
