FlexLite HM
Hermetic motor lead wire
Applications
Designed for hermetic motor applications, Raychem
FlexLite HM lead wire offers excellent refrigerant
resistance, shop handling, and mechanical
performance at lower costs than traditional lead wires
for hermetic applications.
FlexLite HM meets the NEMA MW-1000 Refrigerant
Extraction Test for R-22 and R-134a, and is UL
recognized for use at 125°C and 600 V.
Features and benefits
UL rated operating temperature -20°C to 125°C
Very low extractables in refridgerants.
Excellent shop-handling characteristics offering
compatibility with automatic stripping machines.
Light weight, small size.
Tough insulation material.
Gauge sizes from 10-24 AWG.
Operating temperature to 125°C.
Available in:
Americas
Europe
Asia Pacific
Conductor
Bare copper
Insulation
Modified polyester
9-50 Wire and Cable
Fax-on-demand
US only
(800) 260-9099
Outside US
(650) 257-2301
Visit our website at www.tycoelectronics.com
Specifications/approvals
Series
UL
HM
Style 10223
Temperature rating 125°C
CUL
Recognized
CSA
Certified AWMIA/B
Raychem
WCD-3105
Construction details—dimensions in
mm/in
Finished wire
Conductor
Nominal
Diameter
Wire
resistance
size Stranding Diameter
at 20°C
Lower
(AWG) (no. x AWG) (target value) Ω/km
(Ω/1000 ft)
spec. limit
10 x 30
16 x 30
26 x 30
41 x 30
65 x 30
104 x 30
.965
(.0380)
31
(9.45)
1.16
(.0455)
23.6
(7.20)
1.47
(.0580)
15.1
(4.59)
1.85
(.0730)
8.8
(2.68)
2.34
(.0920)
5.35
(1.63)
2.92
(.115)
3.7
(1.12)
1.32
(.052)
1.52
(.060)
1.83
(.072)
2.21
(.087)
2.74
(.108)
3.38
(.133)
Part number
Target
value
1.37
(.054)
1.58
(.062)
1.88
(.074)
2.26
(.089)
2.79
(.110)
3.43
(.135)
Upper
spec. limit
1.42
(.056)
1.63
(.064)
1.93
(.076)
2.31
(.091)
2.84
(.112)
3.48
(.137)
Nominal
weight in
kg/km
(lb/1000 ft)
6.25
(4.2)
8.93
(6.0)
13.24
(8.9)
20.54
(13.8)
34.39
(23.1)
51.21
(34.4)
FLHMK0319-20-* 20
FLHMK0319-18-* 18
FLHMK0319-16-* 16
FLHMK0319-14-* 14
FLHMK0319-12-* 12
FLHMKO319-10-* 10
* Replace asterisk with color code designator:
0 = Black
3 = Orange
7 = Violet
1 = Brown
4 = Yellow
8 = Gray
2 = Red
5 = Green
9 = White
For example: FLHMK0319-18-9 = AWG 18, white
Users should independently evaluate the suitability of the product for their application.
Before ordering check with factory for most current data.
