TRANSISTOR
SOCKETS
SERIES 917 • SURFACE AND THROUGH-HOLE MOUNT
.018-.025
.010 .018
•
Series 917 TO package sockets are available
.110
.165
.086
.145
•
•
.020 DIA.
.125
•
45
.394
•
B=.200
•
in 3, 4, 8 and 10 positions
Two 8 pin versions feature pin centers on .200”
or .230” circle
Series 917...005 use MM #1705 and MM
#1802 pins, see pages 168 and 169 for details.
Receptacles use Hi-Rel, 4 finger #30 contact
rated at 3 amps. See page 253 for details
Series 917...001 uses MM #1701 pins. See page
171 for details. Receptacles use Hi-Rel, 4 finger
#30 contact rated at 3 amps. See page 253 for
details
Insulators are high temperature thermoplastic,
suitable for all soldering operations
For Electrical, Mechanical and Environmental
Data, see page 264 for details
ORDERING INFORMATION
Transistor Sockets (Through-Hole Mount)
B=.200
B=.200
Type
36
Circle
Dia.
0.200
0.200
0.200
0.230
0.230
Number
of Pins
3
4
8
8
10
Ordering Information
917-XX-103-41-005000
917-XX-104-41-005000
917-XX-108-41-005000
917-XX-208-41-005000
917-XX-210-41-005000
B=.230
.015-.025
.010 * .018
B=.230
TO-5
TO-5
TO-5
TO-100
TO-100
.110
.200
.086
.146
.046 DIA.
Transistor Sockets (Surface Mount)
Type
TO-5
TO-5
TO-5
TO-100
TO-100
.034 DIA.
Circle
Dia.
0.200
0.200
0.200
0.230
0.230
Number
of Pins
3
4
8
8
10
Ordering Information
917-XX-103-41-001000
917-XX-104-41-001000
917-XX-108-41-001000
917-XX-208-41-001000
917-XX-210-41-001000
45
M
M
.394
PAGE 136 | IC SOCKETS / TO SOCKETS
B=.200
Tape and Reel Packaging: (Surface Mount ONLY)
M
M
M
M
Ordering Information:
917-XX-XXX-41-001799
Available on 24mm wide tape, 730 parts per 13” reel
B=.200
B=.200
36
XX=Plating Code
See Below
RoHS - 2
2011/65/EU
M
M
M
M
SPECIFY PLATING CODE XX=
Sleeve (Pin)
B=.230
B=.230
91
10
”
Au
93
30
”
Au
41
200
”
Sn
10
”
Au
43
200
”
Sn
30
”
Au
200
”
Sn/Pb 200
”
Sn/Pb
Contact (Clip)
