SHL
CONNECTOR
Emboss Tape
1.0mm pitch/Disconnectable Crimp style connectors
Specifications –––––––––––––––––––
• Current rating: 1.0A AC, DC (AWG #28)
• Voltage rating: 50V AC, DC
• Temperature range:
-
25˚C to
+
85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/ 20m
Ω
max.
After environmental testing/ 40m
Ω
max.
• Insulation resistance: 100M
Ω
min.
• Withstanding voltage: 500V AC/minute
• Applicable wire: AWG #32 to #28
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
• Thin design
• Low insertion force
• Deformation preventive design
Standards ––––––––––––––––––––––
1
Certified LR20812
Offset type
0.6
0
Recognized E60389
Normal type
1
7.2
1.2
4.3
0.6
1
7.2
3.35
4.6
4.3
0.7
4.5
±0.1
1.7
3.85
5.1
1.7
1.8
0.7
PC board
Header outline
（1.55）
1.6
Header outline
1
0.9
0.9
Note: 1. The above figure is the figure viewed from the connector mounting side.
2. Tolerances are non-cumulative:
±
0.05mm for all centers.
3. The dimensions above should serve as a guideline. Contact JST for details.
Contact
Model No.
SSHL-003T-P0.2
mm
2
0.7
Applicable wire
Insulation O.D. (mm)
AWG#
32∼28
0.4∼0.8
Q'ty /
reel
41,000
0.032∼0.08
Material and Finish
4.75
2
0.5
0.8
2.35
0.8
0.4
Phosphor bronze, tin-plated (reflow treatment)
RoHS compliance
Note: Contact JST for gold-plated products.
Contact
Crimping
machine Crimp applicator
MKS-L-10-3
*MKS-SC
Applicator
Dies
Crimp applicator with dies
SSHL-003T-P0.2
AP-K2N
MK/SSH/L-003-02 APLMK SSH/L003-02
SC/SSH/L-003-02 APLSC SSH/L003-02
Note: *Strip-crimp applicator
Contact JST for applicable wires in case that it is not usable due to wire size.
1
1.4
SHL CONNECTOR
Housing
Circuits
2
5
Marking by
every 5 circuit
Circuit No.1
mark
Model No.
With protrusions
SHLP-02V-S-B
SHLP-05V-S-B
SHLP-06V-S-B
SHLP-07V-S-B
SHLP-08V-S-B
SHLP-10V-S-B
SHLP-11V-S-B
SHLP-12V-S-B
SHLP-14V-S-B
SHLP-16V-S-B
SHLP-20V-S-B
SHLP-22V-S-B
SHLP-26V-S-B
SHLP-30V-S-B
Dimensions (mm)
A
1.0
4.0
5.0
6.0
7.0
9.0
10.0
11.0
13.0
15.0
19.0
21.0
25.0
29.0
B
4.6
7.6
8.6
9.6
10.6
12.6
13.6
14.6
16.6
18.6
22.6
24.6
28.6
32.6
Q'ty /
box
6,000
3,000
3,000
3,000
3,000
2,000
2,000
2,000
2,000
1,000
1,000
1,000
1,000
1,000
6
1.75
7
8
10
2.9
11
12
14
16
20
22
26
30
1
A
B
5.7
1.15
Material
PBT, UL94V-0, natural (white)
RoHS compliance
Shrouded header
Normal type
Model No.
Circuits
2
B
A
1
1.75
4.3
0.7
Normal type
SM02B-SHLS-TF
SM05B-SHLS-TF
SM06B-SHLS-TF
SM07B-SHLS-TF
SM10B-SHLS-TF
SM11B-SHLS-TF
SM12B-SHLS-TF
SM16B-SHLS-TF
SM22B-SHLS-TF
SM26B-SHLS-TF
SM30B-SHLS-TF
Offset type
—
—
—
—
—
—
—
—
—
—
—
Material and Finish
Q'ty /
Normal type Offset type reel
A
B
A
B
1.0
—
4,500
4.8
—
4.0
5.0
6.0
7.0
9.0
10.0
11.0
7.8
8.8
9.8
10.8
12.8
13.8
14.8
Insulation O.D. (mm)
5
6
7
8
10
11
12
14
—
—
—
7.0
—
—
—
12.0
4,500
4,500
4,500
4,500
4,500
4,500
4,500
SM08B-SHLS-TF SM08B-SHLS-1-TF
—
—
—
—
—
—
—
—
—
—
—
—
—
—
Circuit No.1
SM14B-SHLS-TF SM14B-SHLS-1-TF
13.0 16.8 13.0 18.0 4,500
15.0
18.8
4,500
Offset type
16
20
22
B
A
1
4.3
1.2
SM20B-SHLS-TF SM20B-SHLS-1-TF
19.0 22.8 19.0 24.0 4,500
21.0
25.0
29.0
24.8
28.8
32.8
4,500
4,500
4,500
26
30
1.4
1.75
1.4
Contact: Phosphor bronze, copper-undercoated, tin-plated (reflow treatment)
Housing:
PA, UL94V-0, natural (ivory)
Solder tab: Brass, copper-undercoated, tin-plated (reflow treatment)
Circuit No.1
RoHS compliance
This product displays (LF)(SN) on a label.
Note: Contact JST for the headers with gold-plated pins.
