SX5618UL datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> SX5618UL

SX5618UL: DescriptionRectifier Diode, 1 Element, 1A, Silicon, HERMETIC SEALED, GLASS, MELF-1, 2 PIN; CategoryDiscrete semiconductor diode; File Size46KB，3 Pages; ManufacturerSENSITRON; Websitehttp://www.sensitron.com/

Download Datasheet Parametric View All

SX5618UL Overview

Rectifier Diode, 1 Element, 1A, Silicon, HERMETIC SEALED, GLASS, MELF-1, 2 PIN

SX5618UL Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	SENSITRON
Parts packaging code	MELF
package instruction	E-LELF-R2
Contacts	2
Reach Compliance Code	compliant
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JESD-30 code	E-LELF-R2
JESD-609 code	e0
Number of components	1
Number of terminals	2
Maximum output current	1 A
Package body material	GLASS
Package shape	ELLIPTICAL
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum reverse recovery time	2 µs
surface mount	YES
Terminal surface	TIN LEAD
Terminal form	WRAP AROUND
Terminal location	END
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

SENSITRON

SEMICONDUCTOR

TECHNICAL DATA

DATA SHEET 874, REV. B

1N5614/UL

1N5616/UL

1N5618/UL

1N5620/UL

1N5622/UL

JAN

JANTX

JANTXV

HERMETIC AXIAL LEAD / MELF

GENERAL PURPOSE RECTIFIER

DESCRIPTION: A 200/400/600/800/1000 VOLT, 1.0 AMP, AXIAL LEAD/SURFACE MOUNT

2000 NS GLASS RECTIFIER.

MAXIMUM RATINGS

RATING

Peak Inverse Voltage

(PIV)

1N5614

1N5616

1N5618

1N5620

1N5622

Average DC Output

Current (I

) T

= 55

°C

= 100

°C

Peak Single Cycle Surge

Current (I

fsm

)

= 8.3 ms Single

Half Cycle Sine

Wave,

Superimposed On

Rated Load

Junction to Lead

d = 0.375”

Junction to Endcap

CONDITIONS

All ratings are at T

= 25

C unless otherwise specified.

MIN

TYP

200

400

600

800

1000

1.0

0.75

Amps(pk)

Amps

MAX

UNIT

Vdc

Thermal Resistance (

θJL

)

Thermal Resistance (θ

JEC

)

Operating and Storage

Temp. (T

& T

stg

)

-65

+175

°C/W

°C

ELECTRICAL CHARACTERISTICS

CHARACTERISTIC

Maximum Forward

Voltage (V

)

Maximum Instantaneous

Reverse Current At Rated

(PIV)

Maximum Reverse

Recovery Time

CONDITIONS

= 3.0A (300

μsec

pulse, duty cycle <

2%)

= 25° C

= 100° C

= 0.5A, I

= 1.0A

= 0.25A

MIN

TYP

MAX

1.3

UNIT

Volts

0.5

2000

μAmps

•

221 West Industry Court Deer Park, NY 11729-4681 Phone (631) 586 7600 Fax (631) 242 9798

•

World Wide Web - www.sensitron.com

•

E-mail Address - sales@sensitron.com

•

SENSITRON

TECHNICAL DATA

DATA SHEET 874, REV. B

1N5614/UL

1N5616/UL

1N5618/UL

1N5620/UL

1N5622/UL

JAN

JANTX

JANTXV

DISCLAIMER:

1- The information given herein, including the specifications and dimensions, is subject to change without prior notice to improve product

characteristics. Before ordering, purchasers are advised to contact the Sensitron Semiconductor sales department for the latest version of the

datasheet(s).

2- In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation, traffic equipment, medical

equipment , and safety equipment) , safety should be ensured by using semiconductor devices that feature assured safety or by means of users’

fail-safe precautions or other arrangement .

3- In no event shall Sensitron Semiconductor be liable for any damages that may result from an accident or any other cause during operation of

the user’s units according to the datasheet(s). Sensitron Semiconductor assumes no responsibility for any intellectual property claims or any

other problems that may result from applications of information, products or circuits described in the datasheets.

4- In no event shall Sensitron Semiconductor be liable for any failure in a semiconductor device or any secondary damage resulting from use at

a value exceeding the absolute maximum rating.

5- No license is granted by the datasheet(s) under any patents or other rights of any third party or Sensitron Semiconductor.

6- The datasheet(s) may not be reproduced or duplicated, in any form, in whole or part, without the expressed written permission of Sensitron

Semiconductor.

7- The products (technologies) described in the datasheet(s) are not to be provided to any party whose purpose in their application will hinder

maintenance of international peace and safety nor are they to be applied to that purpose by their direct purchasers or any third party. When

exporting these products (technologies), the necessary procedures are to be taken in accordance with related laws and regulations.

•

221 West Industry Court Deer Park, NY 11729-4681 Phone (631) 586 7600 Fax (631) 242 9798

•

World Wide Web - www.sensitron.com

•

E-mail Address - sales@sensitron.com

•
