5-569491-1 Product Details
Live Product Chat
Product Photo
PC Card (PCMCIA) Connectors & Accessories
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5-569491-1
T E I nternal N umber: 5 - 5 6 9 4 9 1 - 1
Product Highlights:
l
I/O C onnector
l
C onnector Type = Header
l
PC B Offset = 0.00 mm
l
Lead Type = Surface Mount - Inline leads
l
Number of Positions = 15
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
HEADER ASSEMBLY, SHIELDED, DUAL 15, TYPE II, TM SERI...
(PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
INFOPORT SERIES II C ABLE C ONNEC TOR AND PRINTED C IRC U...
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= I/O C onnector
l
C onnector Type
= Header
l
Number of Positions
= 15
l
Shielded
= Yes
l
Mating Polarization
= With
l
Mating Polarization Type
= Keyed 1
l
Holddowns = Without
l
Product Series = Series III
l
Mating C onnector Lock = Without
l
C olor = Natural
l
Shield Material = Stainless Steel
l
Proprietary Name = INFOPORT
l
Number of C ontacts Loaded = 15
l
C omment = Receptacle should have the same PC B offset as Header.
Termination Related Features:
l
Solder Tail C ontact Plating = Tin-Lead (150)
Body Related Features:
l
PC B Offset (mm [in])
= 0.00 [0.000]
l
Lead Type
= Surface Mount - Inline leads
l
Striker Plate Material = Stainless Steel
l
C enterline (mm [in]) = 0.80 [0.031]
l
Shield Plating = Tin-Lead
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (10) over Palladium
Nickel
l
Region = Americas
l
C ontact Base Material = Phosphor Bronze
l
C ontact Underplating = Nickel
Housing Related Features:
l
Housing Material = Nylon
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Reflow solder capable to 245?C ,
Reflow solder capable to 260?C
Conditions for Usage:
l
Terminate To = Printed C ircuit Board
Packaging Related Features:
l
Packaging Method
= Tape Mounted on Reel
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
