TrueNet
®
Category 5e
Structured Cabling Systems
The TrueNet Category 5e solution is a fully integrated family of precisely tuned components each designed to operate at optimum
performance with the other. This solution is unmatched in data throughput and is supported by the most comprehensive and thorough
warranty in the industy: the TrueNet Zero Bit-Error warranty. The warranty guarantees that the structured cabling system will remain error
free for a full 5 years and includes a 20-year electrical performance and free of defect warranty. The result is a remarkable advanced and
high performing end-to-end channel guaranteed beyond the typical industry requirements to maximize network throughput and minimize
downtime. Numerous component options are available for versatility and flexible adaptation to meet any infrastructure requirement.
Data Cables
Features
• Patented impedance matching for
zero bit-errors
• Features AirES
®
technology
• Manufactured with lead-free
materials
Description
4-pair plenum data cable
4-pair riser data cable
Catalog Number
TN5ESP-XXYY
TN5ESR-XXYY
XX = Jacket Color: BL = Blue, WT = White, GY = Gray, GN = Green, YL = Yellow, RD = Red
YY = Length: 02 = 1000 ft, 04 = 2000 ft, 05 = 2500 ft, RB = 1000 ft reel in a box, II = Relex
Patch Panels
Features
• 1 RU 24-port design provides high
density and flexibility
• Wire can be terminated with either a
KRONE
®
or 110 tool
• Rear wire manager included
• Designed to support gigabit ethernet
transmission speeds
Description
1 RU 24-port patch panel; silkscreen
2 RU 48-port patch panel; silkscreen
1 RU 24-port patch panel; fascia
2 RU 48-port patch panel; fascia
Catalog Number
6653 1 585-24
6653 1 585-48
6653 1 587-24
6653 1 587-48
Dynamic Right/Left
Angle Patch Panels
Features
• Patented right/left angle eases stress on patch
cords allowing for easy cable management
• 45-degree silver-plated IDCs provide secure
reliable gas-tight connections
• Wire can be terminated with either a KRONE
or 110 tool
• Universal A/B wiring label
Description
1 RU 24-port right/left angle
patch panel
2 RU 48-port right/left angle
patch panel
Cable bar manager; black
Catalog Number
PP24AC5ET
PP48AC5ET
ADCCMR-A
Modular Jacks
(K610)
Features
• 45-degree silver-plated IDCs provide
secure reliable gas-tight connections
• Wire can be terminated with either a
KRONE or 110 tool
• Universal A/B wiring label
• Compatible with any TrueNet modular
faceplate, modular furniture faceplate,
surface box and modular patch panel
Description
KM610 RJ45 UTP modular 568 A/B jack
KM610 RJ45 UTP modular USOC jack
KM610 RJ11 UTP modular USOC jack
Catalog Number
6467 5 181-XX
6467 5 198-XX
6467 5 195-XX
XX = Jack Color: 00 = Gray, 10 = Ivory, 20 = White, 22 = Electrical Ivory, 30 = Black, 40 = Blue, 50 = Red, 60 = Orange,
70 = Violet, 80 = Green, 90 = Yellow
www.adc.com
•
+1- 9 52- 93 8 - 8 0 8 0
•
1-800-366-3891
Mini Patch Panels
Features
• 45-degree silver-plated IDCs
provide secure reliable gas-tight
connections
• Can be mounted on universal
mount system, rod mount or
back mount frame
• Universal A/B wiring labels
Description
6-port universal mount system/mini patch
panel type 105
Catalog Number
6653 1 607-00
Patch Cords
Features
• Impedance matched patch cord for maximum
throughput
• Patented AirES technology
• Up to 28% smaller outer diameter than other
patch cords
• UL 1863 listed and Category 5e performance
verified
Description
RJ45-RJ45 plug UTP T568B
PVC patch cord
RJ45-RJ45 plug UTP T568A
PVC patch cord
RJ45-RJ45 plug UTP crossover
PVC patch cord
Catalog Number
TP5ETA-XXYY
TP5ETA0XXYY
TP5ETACXXYY
XX = Color: WT = White, RD = Red, BL = Blue, YL = Yellow, GN = Green, GY = Gray
YY = Length: 04 = 4 ft, 07 = 7 ft, 10 = 10 ft, 15 =15 ft, 25 = 25 ft, 50 = 50 ft
Contact ADC for custom lengths and colors.
HighBand
®
10
Blocks
Features
Description
Catalog Number
6468 2 061-00
6636 1 590-46
• Pre-terminated blocks reduce installation time 10-pair HighBand block
• Test port provides “look-both-ways” testing
100-pair field assembly kit with
and circuit monitoring using ADC test cords
universal mount system
• Meets TIA/EIA Category 5e component
specifications
• Choice of 3 mounting options: universal mount
system, back mount frame or rod mount
Faceplate
Mounting Options
Features
• UL 1863
• UL 94-V0
• Multiple mounting options for
all your voice and data needs
Description
2-port flush mount faceplate
4-port flush mount faceplate
4-port all-fit surface mount box
4-port furniture faceplate
Catalog Number
6644 1 152-XX
6644 1 154-XX
6644 1 224-XX
6644 1 144-XX
XX = Color: 01 = White, 02 = Ivory, 03 = Gray, 04 = Black, 22 = Electrical Ivory
See ADC TrueNet Catalog for a wide range of faceplates, surface mount boxes and multimedia boxes.
Web Site: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC’s global sales office locations, please refer to our web site.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may verify
product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc. views its patent
portfolio as an important corporate asset and vigorously enforces its patents. Products orfeatures contained herein may be
covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
102346AE 3/06 Original © 2006 ADC Telecommunications, Inc. All Rights Reserved
