2-176970-2 Product Details
Live Product Chat
1.27 [.050] Series II and Series III Connectors
5 of 6 EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
No Im a ge Ava ila ble
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
2-176970-2
T E I nternal N umber: 2 - 1 7 6 9 7 0 - 2
Product Highlights:
l
Mating Type = Receptacle
l
Number of Positions = 20
l
Terminate To Printed C ircuit Board
l
Right Angle Mount Angle
l
No PC B Retention Feature
View all Features
Obsolete
C ontact Product Information
C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Mating Type
= Receptacle
l
Number of Positions
= 20
l
Mount Angle
= Right Angle
l
PC B Retention Feature
= No
l
Mating C onnector Lock
= Without
l
Product Series
= Series II
l
C olor = Black
l
Shell Material = Steel
Mechanical Attachment:
l
Panel Attachment
= With
l
Tine Plate Material = Thermoplastic
Termination Related Features:
l
Termination Post Length (mm [in]) = 3.10 [0.122]
l
Solder Tail C ontact Plating = Tin-Lead over Nickel
Body Related Features:
l
C enterline (mm [in]) = 1.27 [0.050]
l
Shell Plating = Nickel
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (30)
l
C ontact Base Material = C opper Alloy
Housing Related Features:
l
Housing Material Temperature
= Standard
l
Housing Material = Zinc Diecast
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant, 5 of 6 C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Conditions for Usage:
l
Terminate To
= Printed C ircuit Board
Other:
l
Brand = AMP
