Storage Chokes
DSH
and
DSHP
Series
,
vertical housing
Nominal current:
Nominal inductance:
Max. working voltage:
Application range:
Isolations voltage:
Climatic category:
Plastic case:
Potting resin:
0.45 - 6.3 A @
ϑ
a 70°C
12 - 2000 µH/ tol.
±
15%
600 VDC
up to 1 MHz
2 kV eff. / wdg.-ambient
40/125/21 acc. to IEC 60068-1
UL 94 V-0
UL 94 V-0
This range of chokes enable vertical mounting, thus reducing the
area of the PC board used. Finest quality core materials allow the
highest electrical performance with minimum component volume.
Good design with easy assembly allows good cost/performance ra-
tio. This type of choke is essential in the field of power electronics,
e.g. switching power supplies, chopper amplifiers, DC drives and step-
per motor controls.
DSH
Storage chokes, used as energy stores in switch mode
DSHP
power supplies. Principle features:
- reduced magnetic reversal
- constant inductance at high alternating field modulation
and high DC magnetisation.
Environmental Ratings:
The
DSH choke
can only be used with high frequency alternating
current or with HF-modulated direct current up to 1 MHz, under
consideration of their self heating (I
N
and
DI
at f
0
) and the ambient
temperature (ϑa).
Typical
Ambient temperature
Operating frequency
Nominal DC current
HF-Ripple
SMD-version upon request.
ϑa
f
0
I
N
DI
=
=
=
=
70°C
50 kHz
as per table
20% I
N
Technical Data
Type
DSHP-6148-D6D1
DSHP-6148-01C5
DSH1-14-0.6-140/a
DSH1-14-1.0-50/a
DSH1-14-2.0-12/a
DSH1-22-0.45-2000/a
DSH1-22-0.63-1000/a
DSH1-22-1.0-400/a
DSH1-22-1.4-200/a
DSH1-22-1.8-120/a
DSH1-22-3.15-40/a
DSH1-22-6.3-10/a
DSH1-31-1.6-500/a
DSH1-31-2.0-300/a
DSH1-31-4.0-100/a
DSH1-31-6.3-35/a
I
N
(1)
[A]
L
N
(2)
[µH]
R
cu
(3)
[mΩ]
[MHz]
~ f
Res
Case
48-1
48-1
01-1
01-1
01-1
09-1
09-1
09-1
09-1
09-1
09-1
09-1
19-1
19-1
19-1
19-1
0.6
1.0
0.6
1.0
2.0
0.45
0.63
1.0
1.4
1.8
3.15
6.3
1.6
2.0
4.0
6.3
100
40
140
50
12
2000
1000
400
200
120
40
10
500
300
100
35
550
280
280
100
25
1250
750
300
160
90
33
8
240
140
40
15
(125-ϑa)/55
11
18
8
12
35
0.4
1.8
3
4.8
6.5
14
35
2.5
3.5
6.5
13
Application
(1)
@
ϑa
70°C; current derating 70°C: I = I
N
x
(2)
Nominal inductance measured according to EN 138100,
(3)
Resistance @
ϑa
25°C
see introduction of this catalog, paragraph 3.4
Case 48-1
Typical curve
Case 01-1,
09-1,
19-1
35
