RF, Microwave and Datalink Contacts
for MIL-DTL-38999, SuperNine
®
, Mighty Mouse and
Micro-Crimp
®
Connectors
Low-Loss Matched-Impedance Coaxial Contacts
Selection Guide
50 Ohm Matched-Impedance Contacts
These 50 ohm high frequency contacts provide low insertion loss and improved VSWR
compared to AS39029 coaxial contacts. These snap-in, rear-release contacts are compatible
with MIL-DTL-38999 connectors and Glenair Series 79 Micro-Crimp®, Series 80 Mighty Mouse
and Series 23 SuperNine® connectors.
50 Ohm Matched-Impedance Coaxial Contacts
Cable
Size Max.
Freq.
12
8
12
8
12
12
8
3 GHz
3 GHz
3 GHz
6 GHZ
3 GHz
3 GHZ
Pin Contact
M38999 I-IV
Ser. 79, 80
852-016-03
852-031-02F
852-016-01
852-031-01F
852-016-02
852-018
Socket Contact
M38999
M38999
Series I, III, IV Series II
Series 80
Series 79, 80
852-019-03
852-030-02F
852-019-01
852-030-01F
852-019-02
852-037
852-042F
852-015-03
(N/A)
Page
RG178
RG316
RG316
RG316DS
RG316DS
RG405-FLEX
M17/220-0001
12
10
12
10
12
12
10
852-015-01
(N/A)
852-015-02
852-017
(N/A)
2.5 GHz
852-043F
75 Ohm Matched-Impedance Contacts
These 75 ohm high frequency contacts for up to 4 GHz fre quency range accept aerospace
grade digital video cable. These snap-in, rear-release contacts are compatible with MIL-
DTL-38999 connectors, Glenair Series 79 Micro-Crimp®, Series 80 Mighty Mouse and Series
23 SuperNine® connectors.
75 Ohm Matched-Impedance Coaxial Contacts
Cable
Size Max.
Freq.
8
12
8
12
8
8
4 GHz
3 GHz
4 GHz
4 GHz
4 GHz
4 GHz
Pin Contact
M38999 I-IV
Ser. 79, 80
852-056-02F
852-103-02
852-056-01F
852-103-01
852-082-01F
852-082-02F
Socket Contact
M38999
M38999
Series I, III, IV Series II
Series 80
Series 79, 80
852-057-02F
852-106-02
852-057-01F
852-106-01
852-083-01F
852-083-02F
(N/A)
Page
RG179
RG179
PIC V73263,
V75268, V76261
PIC V73263,
V75268, V76261
PIC V78209
LMR-240-75
14
16
14
16
14
14
9
852-104-02
(N/A)
852-104-01
(N/A)
(N/A)
© 2016 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • High-Speed Contacts
Dimensions in Inches (millimeters) are subject to change without notice.
