BXY43P
HiRel Silicon PIN Diode
•
HiRel Discrete and Microwave Semiconductor
•
Current controlled RF resistors for RF
attenuators and switches
•
High reverse voltage
•
Hermetically sealed microwave package
•
esa
Space Qualified
ESA/SCC Detail Spec. No.: 5513/030
Type Variant No. 04
BXY43P-FP
1.2
1.1
1.2'
1.1'
2
Type
BXY43P
Maximum Ratings
Parameter
Package
FP
Configuration
parallel pair
Symbol
V
R
I
F
P
tot
T
j
T
op
T
sol
T
stg
Value
Marking
-
Unit
Reverse voltage
Forward current
Total power dissipation
1)
Junction temperature
Operating temperature range
Soldering temperature
2)
Storage temperature
150
400
500
150
-55 ... 150
235
-65 ... 175
V
mA
mW
°C
°C
°C
Thermal Resistance
Parameter
Thermal resistance junction-case
1
At
Symbol
R
th(j-c)
Value
100
Unit
K/W
T
S
= 40°C. For
T
S
> 40°C derating is required.
15 sec. maximum. The same terminal shall not be resoldered until 5 minutes have elapsed
2
During
1
2007-08-20
BXY43P
Electrical Characteristics
at
T
A
= 25°C, unless otherwise specified
Symbol
Values
Unit
Parameter
min.
typ. max.
DC Characteristics
Reverse current 1
I
R1
-
-
100 nA
V
R1
= 150 V
Reverse current 2
V
R2
= 100 V
Forward voltage
I
F
= 100 mA
V
F
-
0.97
1
V
I
R2
-
-
10
AC Characteristics
Diode capacitance
V
R
= 50 V,
f
= 1 MHz
Forward resistance 1
I
F1
= 20 µA,
f
= 100 MHz
Forward resistance 2
I
F2
= 1 mA,
f
= 100 MHz
Forward resistance 3
Minority carrier lifetime
I
F
= 10 mA,
I
R
= 6 mA,
I
R
= 3 mA
Matching Requirements
Difference in Forward Resistance 2
1)
Difference in Forwars Resistance 3
1)
1
∆
R
C
T
R
F1
R
F2
R
F3
τ
L
0.4
-
-
-
250
0.6
55
2.2
0.9
650
0.85
70
3
1.5
-
pF
Ω
ns
R
F2
R
F3
-
-
-
-
15
15
%
F
[%]= 100*(RF_Diode2- RF_Diode1)/RF_Diode1
2
2007-08-20
BXY43P
