EM MICROELECTRONIC

- MARIN SA

Reset Circuit with Fixed Delay

Description

The EM6353 is an ultra-low current reset circuit available in a

large variety of configurations and very small packages for

maximum flexibility in all end-applications up to 125°C and

using power supplies between 1.5V and 5.5V.

This circuit monitors the supply voltage of any electronic

system, and generates the appropriate reset signal after a

fixed reset timeout period. The threshold defines the

minimum allowed voltage which guarantees the good

functionality of the system. When V

rises above V

, the

output remains active for an additional delay time. This

allows the system to stabilize before getting fully active.

The EM6353 features three output types: active-low push-

pull, active-low open-drain and active-high push-pull.

Small SC70-5L and SOT23-3L packages as well as ultra-low

supply current of 2.9µA make the EM6353 an ideal choice

for portable and battery-operated devices.

EM6353

Features

200ms reset timeout period (25ms on request)

Ultra-low supply current of 2.9µA (V

=3.3V)

Operating temperature range: -40°C to +125°C

±1.5%

reset threshold accuracy

11 reset threshold voltages V

: 4.63V, 4.4V, 3.08V,

2.93V, 2.63V, 2.2V, 1.8V, 1.66V, 1.57V, 1.38V, 1.31V

3 reset output options:

Active-low

RESET

push-pull

Active-low

RESET

open-drain

Active-high

RESET

push-pull

No external components

Immune to short negative V

transients

Guaranteed Reset valid down to 0.8V

Threshold hysteresis: 2.1% of V

Very small SOT23-3L and SC70-5L packages

Typical Application

RESET

Applications

Mobile phones

Set-top boxes

Video, digital cameras, DVD players and recorders

Modems

Personal computers

Switching hubs

Copiers and fax

Utility meters

EM6353

GND

MPU, DSP

GND

EXT

for open-drain version only

Pin Configuration

(top view)

GND

RESET 2

(RESET)

RESET 1

(RESET)

3 GND

Block Diagram

Oscillator

SOT23-3L

"beta" bonding

4 GND

5 RESET

(RESET)

SOT23-3L

"alpha" bonding

GND 4

RESET

(RESET)

3 NC

2 V

1 NC

Voltage

Reference

Reset

Logic

RESET

SC70-5L

(compatible with SC70-3 by rotating 180°)

GND

Pin Description

SOT23-3L

“beta”

SOT23-3L

“alpha”

SC70-5L

Name

Function

GND

RESET

Ground

Active-low RESET output. RESET remains low for the reset timeout period

after all reset conditions are deasserted and then goes high.

Active-high RESET output. RESET remains high for the reset timeout period

after all reset conditions are deasserted and then goes low.

Supply Voltage (5.5V max.)

Not connected. Not internally connected.

RESET

1,3

N.C.

2007, EM Microelectronic-Marin SA

05/07 – rev.M

www.emmicroelectronic.com
