R1282D Series
PWM Step-up/Step-down DC/DC Controller for LCD/CCD
The R1282D Series are low supply current dual output CMOS-based PWM step-up/step-down DC/DC controllers. R1282D includes a
soft start circuit, an under-voltage lockout circuit (UVLO), and a latch type protection circuit. By simply using inductors, resistors,
capacitors, power MOS, and diodes, as external components, a high-efficiency step-up/step-down DC/DC converter can be easily configured.
The oscillator maximum duty cycle, phase compensation, and soft start time can be set with an external resistor and capacitor.
FEATURES
•
Supply Current (I
DD
) ······································· Typ. 1.4mA (V
IN
=5.5V, EXT at no load)
•
Input Voltage Range (V
IN
) ······························ 2.5V to 5.5V
•
Step-up Feedback Voltage (V
FB1
) ·················· 1.0V
•
Step-down Feedback Voltage (V
FB2
)·············· 1.0V
•
Feedback Voltage Accuracy ··························
±
1.5%
•
Reference Voltage Output (V
REFOUT
) ·············· 1.5V (± 15mV)
•
Oscillator Frequency (f
osc
)···············700kHz
•
UVLO Detect Voltage (V
UVLO
) ··········2.2V
•
Latch Type Protection Circuit··········Delay time for protection
•
•
Typ. 100ms
Package··········································SON-10
Ceramic capacitors can be used. ···10μF or more
BLOCK DIAGRAM
R1282D002A
DTC1
4
TYPICAL APPLICATION
R1282D002A
V
OUT1
C1
C3
SD
L1
V
FB1
5
OSC
1
EXT1
NMOS
R1
CH1
Vref1
1 EXT1
2 GND
C6
C9
R2
R5
R11 C4
R7
4 DTC1
R8
EXT2 10
V
IN
9
PMOS
L2
V
OUT2
AMPOUT1
3
9
V
IN
3 AMPOUT1
V
REFOUT
8
R9
DTC2 7
C5
5 V
FB1
V
FB2
6
R10
SD
R6
R4
C2
C8
C7
R3
V
REFOUT
8
Vrefout
UVLO
2
GND
V
FB2
6
Vref2
10
EXT2
Latch
Delay Circuit
CH2
L1, L2 : 6.8μH, SD : FS1J3, NMOS : IRF7601, PMOS : Si3443DV, C1=C2=10μF
7
DTC2
SELECTION GUIDE
Package
SON-10
Quantity per Reel
3,000 pcs
Part No.
R1282D002A-TR-F
PACKAGE
SON-10
Top View
10 9
8
7
6
TYPICAL CHARACTERISTICS
R1282D002A Efficiency vs. Output Current
8
9 10
Bottom View
6
7
∗
90
80
70
60
50
40
30
20
10
0
L1=6.8μH,C1=10μF,V
OUT2
=2.5V,I
OUT2
=0mA
90
80
70
60
50
40
30
20
10
0
L2=6.8μH,C2=10μF,V
OUT1
=10V,I
OUT1
=0mA
Efficiency
η
(%)
1
2
3
4
5
5
4
3
2
1
1
2
3
4
5
6
7
8
9
10
EXT1
GND
AMPOUT1
DTC1
V
FB1
V
FB2
DTC2
V
REFOUT
V
IN
EXT2
V
OUT1
=5V
V
OUT1
=10V
V
OUT1
=15V
0
50
100
150
Output Current I
OUT
(mA)
200
Efficiency
η
(%)
V
OUT2
=1.8V
V
OUT2
=2.5V
0
100 200 300 400 500
Output Current l
OUT
(mA)
600
∗)
The tab suspension leads on back side are substrate level (GND).
APPLICATIONS
•
Power source for hand-held equipment
No.EK-118-091101
•
Power source for LCD and CCD
Step-up/Step-down DC/DC Converter
