5-534180-2 Product Details
Live Product Chat
.050, .075, .100 Box Connectors
Always EU R oHS/ELV C om pliant
(
Sta te m e nt of C om pliance
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5-534180-2
T E I nternal N umber: 5 - 5 3 4 1 8 0 - 2
Product Highlights:
l
C onnector
l
C onnector Type = Header - Pin
l
1.27 mm C enterline
l
Number of Rows = 2
l
140 Positions
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Additional Product Images:
l
Recommended PC Board Layout
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = C onnector
l
C onnector Type = Header - Pin
l
Number of Positions
= 140
l
Post Size (mm [in]) = 0.23 x 0.46 [.009 x .018]
l
Sealed = No
l
Strain Relief = Without
l
Mount Angle
= Right Angle
l
PC B Mount Style = Surface Mount
l
C olor = Gray
l
PC B Thickness (mm [in]) = 1.37 – 1.78 [0.054 – 0.070]
Termination Related Features:
l
Termination Post Length (mm [in]) = 3.81 [0.150]
l
Solder Tail C ontact Plating = Tin over Nickel
Body Related Features:
l
C enterline (mm [in]) = 1.27 [0.050]
l
Number of Rows
= 2
l
Post Styles = C ard Extender C ontact
l
Staggered Rows
= No
l
Gasket = Without
l
Pin Protection = Without
l
Hybrid = No
l
Jackscrews = Without
l
Stabilizers = Without
Contact Related Features:
l
C ontact Plating, Mating Area, Material = Gold (50)
l
C ontact Base Material = Brass
Housing Related Features:
l
Housing Material = Liquid C rystal Polymer (LC P)
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Reflow solder capable to 245?C ,
Reflow solder capable to 260?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Operation/Application:
l
Application = PC Solder Mount
Other:
l
Brand = AMP
