NEC's
½
W
UPG168TB
L, S-BAND SPDT SWITCH
FEATURES
• SWITCH CONTROL VOLTAGE:
V
cont (H)
= 2.5 to 5.3 V (3.0 V TYP.)
V
cont (L)
=
−0.2
to +0.2 V (0 V TYP.)
• LOW INSERTION LOSS:
L
INS1
= 0.30 dB TYP. @ f = 0.5 to 1.0 GHz, V
cont
= 3.0 V/0 V
L
INS2
= 0.40 dB TYP. @ f = 2.0 GHz, V
cont
= 3.0 V/0 V
L
INS3
= 0.90 dB MAX. @ f = 2.0 to 2.5 GHz, V
cont
= 3.0 V/0 V
• HIGH ISOLATION:
ISL1 = 27 dB TYP. @ f = 0.5 to 2.0 GHz, V
cont
= 3.0 V/0 V
ISL2 = 18 dB MIN. @ f = 2.0 to 2.5 GHz, V
cont
= 3.0 V/0 V
• POWER HANDLING:
P
in (1 dB)
= +26.5 dBm TYP. @ f = 1.0 GHz, V
cont
= 3.0 V/0 V
• HIGH-DENSITY SURFACE MOUNTING:
6-pin super minimold package (2.0 × 1.25 × 0.9 mm)
DESCRIPTION
NEC's UPG168TB is a GaAs MMIC L, S-band SPDT
(Single Pole Double Throw) switch for mobile phone and L,
S-band applications.
This device can operate from 0.5 to 2.5 GHz, with low insertion
loss and high isolation.
This device is housed in a 6-pin super minimold package,
suitable for high-density surface mount assembly.
APPLICATIONS
• L-band digital cellular or cordless telephones
• PCS, W-LAN, WLL and Bluetooth
TM
• Short Range Wireless
ORDERING INFORMATION
Part Number
UPG168TB-E4
Package
6-pin super minimold
Marking
G2T
Supplying Form
•
Embossed tape 8 mm wide
•
Pin 1, 2, 3 face the perforation side of the tape
•
Qty 3 kpcs/reel
Remark
To order evaluation samples, contact your nearby sales ofÞce.
Part number for sample order: UPG168TB
Caution
Observe precautions when handling because these devices are sensitive to electrostatic discharge.
California Eastern Laboratories
UPG168TB
PIN CONNECTION DIAGRAM
(Top View)
1
2
3
6 1
5 2
4 3
(Top View)
6 6
5 5
4 4
(Bottom View)
1
2
3
Pin No.
1
2
3
4
5
6
Pin Name
OUTPUT2
GND
OUTPUT1
V
Cont1
INPUT
V
Cont2
TRUTH TABLE
Vcont1
Low
High
Vcont2
High
Low
INPUT−OUTPUT1
ON
OFF
INPUT−OUTPUT2
OFF
ON
ABSOLUTE MAXIMUM RATINGS
(T
A
= 25°C, unless otherwise speciÞed)
Parameter
Switch Control Voltage
Input Power
Power Dissipation
Operating Ambient Temperature
Storage Temperature
Symbol
V
cont
P
in
P
D
T
A
T
stg
Ratings
−6.0
to +6.0
Note1
+28
150
Note2
−45
to +85
−55
to +150
Unit
V
dBm
mW
°C
°C
G2T
Parameter
N
ote
1.
Mounted on double-sided copper-clad 50
×
50
×
1.6 mm epoxy glass PWB, T
A
= +85°C
2.
V
cont1
−
V
cont2
≤
6.0 V
RECOMMENDED OPERATING RANGE
(T
A
= 25°C, unless otherwise speciÞed)
Symbol
V
cont (H)
V
cont (L)
MIN.
2.5
−0.2
TYP.
3.0
0
MAX.
5.3
0.2
Unit
V
V
Switch Control Voltage (H)
Switch Control Voltage (L)
UPG168TB
ELECTRICAL CHARACTERISTICS
(T
A
= +25°C, V
cont
= 3.0
V/0 V, DC blocking capacitors = 51 pF, unless otherwise speciÞed)
Parameter
Insertion Loss 1
Insertion Loss 2
Insertion Loss 3
Isolation 1
Isolation 2
Input Return Loss 1
Input Return Loss 2
Output Return Loss 1
Output Return Loss 2
1 dB Gain Compression
Input Power
Note
Switch Control Speed
Switch Control Current
Symbol
L
INS1
L
INS2
L
INS3
ISL1
ISL2
RL
in1
RL
in2
RL
out1
RL
out2
P
in (1 dB)
t
SW
I
cont
Test Conditions
f = 0.5 to 1.0 GHz
f = 2.0 GHz
f = 2.0 to 2.5 GHz
f = 0.5 to 2.0 GHz
f = 2.0 to 2.5 GHz
f = 0.5 to 2.0 GHz
f = 2.0 to 2.5 GHz
f = 0.5 to 2.0 GHz
f = 2.0 to 2.5 GHz
f = 1.0 GHz
MIN.
−
−
−
22
18
13
11
13
11
+22.0
−
−
TYP.
0.30
0.40
−
27
−
19
−
19
−
+26.5
50
0.5
MAX.
0.55
0.65
0.90
−
−
−
−
−
−
−
200
10
Unit
dB
dB
dB
dB
dB
dB
dB
dB
dB
dBm
ns
A
Note
P
in (1 dB)
is the measured input power level when the insertion loss increases 1 dB more than that of linear range.
STANDARD CHARACTERISTICS FOR REFERENCE
(T
A
= +25°C, V
cont
= 3.0 V/0 V, DC blocking capacitors = 51 pF, unless otherwise speciÞed)
Parameter
0.1 dB Gain Compression
Input Power
Note
Symbol
P
in (0.1 dB)
Test Conditions
f = 1.0 GHz
MIN.
−
TYP.
+23.0
MAX.
−
Unit
dBm
Note
P
in (0.1 dB)
is the measured input power level when the insertion loss increases 0.1 dB more than that of linear range.
