1461387-8

Description
POWER/SIGNAL RELAY, SPST, MOMENTARY, 0.09A (COIL), 6VDC (COIL), 540mW (COIL), 10A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT
CategoryMechanical and electronic products    relay
File Size92KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

1461387-8 Overview

POWER/SIGNAL RELAY, SPST, MOMENTARY, 0.09A (COIL), 6VDC (COIL), 540mW (COIL), 10A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT

1461387-8 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerTE Connectivity
package instructionROHS COMPLIANT
Reach Compliance Codecompliant
ECCN codeEAR99
body width12.8 mm
body height20.6 mm
Body length or diameter29.2 mm
Maximum coil current (DC)0.09 A
Coil power540 mW
Coil resistance68 Ω
Maximum coil voltage (DC)6 V
Coil/Input Power TypeDC
Maximum contact current (AC)10 A
Maximum contact current (DC)10 A
Contact/Output Power TypeAC/DC
Installation featuresTHROUGH HOLE-STRAIGHT MOUNT
physical size29.2mm x 12.8mm x 20.6mm
GuidelineCSA; SEMKO; SEV; UL; VDE
Relay actionMOMENTARY
Relay functionSPST
Relay typePOWER/SIGNAL RELAY
surface mountNO
Termination typeSOLDER
Base Number Matches1

Preview

Download Datasheet
OMIT-SH-106LM,394 Product Details
Mid-Ran ge PC Board Re lays
Converted to EU RoHS/ELV Compliant
(
Statement of Compliance
)
Previous 1
...
6 7 8
[9]
10
...
20 Next
Quick Links
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Compare Products
Contact Us About This Product
Product Highlights:
OMIT Series
Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
Contact Current Rating = 10 Amps.
Monostable Coil Magnetic System
Without Coil Suppression Diode
View all Features
|
Find Similar Products
O MIT-SH-106LM,394
Active
Documentation & Additional Information
Product Drawings:
OMIT-SH-D/LM SPEC,394 CUSTOMER DRAWING
(PDF, English)
Catalog Pages/Data Sheets:
None Available
Additional Information:
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Product Line Information
Additional Product Images:
Schematic
Wiring Diagram
PCB Layout (Bottom Surface)
Related Products:
Tooling
List all Documents
Product Features
(Ple ase u se the Produ ct Drawin g for all de sign activity)
Product Type Features:
Termination Type
= Through Hole
Electrical Characteristics:
Contact Current Rating (Amps.)
= 10
Coil Resistance (?)
= 68
Coil Power, Nominal (mW)
= 540
Actuating System
= DC
Input Voltage (VDC)
= 6
Body Related Features:
Series
= OMIT
Polarized = No
Contact Related Features:
Mounting Options
= PC Board
Enclosure
= Sealed
FCC Part 68 Isolation = No
Relay Type = PCB
Contact Material
= Silver Tin Oxide
Approx. Dimensions (L x W x H) (mm [in]) = 29.20 x 12.80 x 20.60 [1.151
x .504 x .812]
Approved Standards = UL Recognized, CSA Certified, VDE Component
Mark, SEMKO, SEV Approved
Other:
Brand = OEG
Configuration Related Features:
Contact Arrangement
= 1 Form A, SPST-NO, 1 N/O
Coil Magnetic System
= Monostable
Coil Suppression Diode
= Without
Coil Selection Criteria
= Nominal Voltage
Coil Latching = Without
LED Indicator
= Without
Industry Standards:
RoHS/ELV Compliance
= RoHS compliant, ELV compliant
Lead Free Solder Processes
= Wave solder capable to 240C, Wave solder
capable to 260C, Wave solder capable to 265C
RoHS/ELV Compliance History = Converted to comply with RoHS
directive
