Alaska
®
88E1116R Technical Product Brief
Gigabit Ethernet Transceiver
Document Conventions
Note:
Provides related information or information of special importance.
Caution:
Indicates potential damage to hardware or software, or loss of data.
Warning:
Indicates a risk of personal injury.
Document Status
Doc Status: Advance
Technical Publications: 1.00
For more information, visit our website at:
www.marvell.com
Disclaimer
No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose,
without the express written permission of Marvell. Marvell retains the right to make changes to this document at any time, without notice. Marvell makes no warranty of any
kind, expressed or implied, with regard to any information contained in this document, including, but not limited to, the implied warranties of merchantability or fitness for any
particular purpose. Further, Marvell does not warrant the accuracy or completeness of the information, text, graphics, or other items contained within this document.
Marvell products are not designed for use in life-support equipment or applications that would cause a life-threatening situation if any such products failed. Do not use
Marvell products in these types of equipment or applications.
With respect to the products described herein, the user or recipient, in the absence of appropriate U.S. government authorization, agrees:
1) Not to re-export or release any such information consisting of technology, software or source code controlled for national security reasons by the U.S. Export Control
Regulations ("EAR"), to a national of EAR Country Groups D:1 or E:2;
2) Not to export the direct product of such technology or such software, to EAR Country Groups D:1 or E:2, if such technology or software and direct products thereof are
controlled for national security reasons by the EAR; and,
3) In the case of technology controlled for national security reasons under the EAR where the direct product of the technology is a complete plant or component of a plant,
not to export to EAR Country Groups D:1 or E:2 the direct product of the plant or major component thereof, if such direct product is controlled for national security reasons
by the EAR, or is subject to controls under the U.S. Munitions List ("USML").
At all times hereunder, the recipient of any such information agrees that they shall be deemed to have manually signed this document in connection with their receipt of any
such information.
Copyright © 1999–2011. Marvell International Ltd. All rights reserved. Marvell, Moving Forward Faster, the Marvell logo, Alaska, AnyVoltage, DSP Switcher, Fastwriter,
Feroceon, Libertas, Link Street, PHYAdvantage, Prestera, TopDog, Virtual Cable Tester, Yukon, and ZJ are registered trademarks of Marvell or its affiliates. CarrierSpan,
LinkCrypt, Powered by Marvell Green PFC, Qdeo, QuietVideo, Sheeva, TwinD, and VCT are trademarks of Marvell or its affiliates.
Patent(s) Pending—Products identified in this document may be covered by one or more Marvell patents and/or patent applications.
Doc. No. MV-S105539-00 Rev. --
Page 2
Document Classification: Proprietary Information
Copyright © 2011 Marvell
May 9, 2011, Advance
Alaska
®
88E1116R Technical Product Brief
Gigabit Ethernet Transceiver
O
VERVIEW
The Alaska
®
88E1116R Gigabit Ethernet Transceiver
is a physical layer device containing a single Gigabit
Ethernet transceiver. The transceiver implements the
Ethernet physical layer portion of the 1000BASE-T,
100BASE-TX, and 10BASE-T standards. It is manu-
factured using standard digital CMOS process and
contains all the active circuitry required to implement
the physical layer functions to transmit and receive
data on standard CAT 5 unshielded twisted pair.
The 88E1116R device supports the RGMII (Reduced
pin count GMII) for direct connection to a MAC/Switch
port.
The 88E1116R device integrates MDI interface termi-
nation resistors into the PHY. This resistor integration
simplifies board layout and reduces board cost by
reducing the number of external components. The new
Marvell
®
calibrated resistor scheme will achieve and
exceed the accuracy requirements of the IEEE 802.3
return loss specifications.
The 88E1116R device can run off a single 1.8V, 2.5V,
or 3.3V supply. Alternatively if the regulators are not
used then the 88E1116R device can run off 1.8V
and1.2V supply.
The 88E1116R device has two regulators to generate
all required voltages. The 88E1116R device supports
1.8V, 2.5V, and 3.3V HSTL/SSTL and 2.5V LVCMOS I/
O Standards
The 88E1116R device incorporates the Marvell® Vir-
tual Cable Tester
®
(VCT™) feature, which uses Time
Domain Reflectometry (TDR) technology for the
remote identification of potential cable malfunctions,
thus reducing equipment returns and service calls.
Using VCT, the Alaska 88E1116R device detects and
reports potential cabling issues such as pair swaps,
pair polarity and excessive pair skew. The device will
also detect cable opens, shorts or any impedance mis-
match in the cable and reporting accurately within one
meter the distance to the fault.
The 88E1116R device uses advanced mixed-signal
processing to perform equalization, echo and crosstalk
cancellation, data recovery, and error correction at a
gigabit per second data rate. The device achieves
robust performance in noisy environments with very
low power dissipation.
F
EATURES
•
10/100/1000BASE-T IEEE 802.3 compliant
•
Four RGMII timing modes - This eliminates the
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
need for adding trace delays on the PCB
Supports LVCMOS, SSTL, and HSTL I/O Stan-
dards on the RGMII interface
Integrated MDI interface termination resistors that
eliminate twelve passive components
Energy Detect and Energy Detect+ low power
modes
Three loopback modes for diagnostics
“Downshift” mode for two-pair cable installations
Fully integrated digital adaptive equalizers, echo
cancellers, and crosstalk cancellers
Advanced digital baseline wander correction
Automatic MDI/MDIX crossover at all speeds of
operation
Automatic polarity correction
IEEE 802.3u compliant Auto-Negotiation
Software programmable LED modes including LED
testing
Supports IEEE 1149.1 JTAG
MDC/MDIO Management Interface
CRC checker, packet counter
Packet generation
Virtual Cable Tester (VCT)
Auto-Calibration for MAC Interface outputs
Coma Mode support
Requires a single 1.8V supply
I/O pads can be supplied with 1.8V, 2.5V, or 3.3V
Two regulators generate all required voltages.
Regulator can be supplied with 1.8V, 2.5V or 3.3V.
Commercial grade
64-Pin QFN package
M
a
g
n
e
t
i
c
s
Integrated Passive
Termination
10/100/1000 Mbps
Ethernet MAC
88E1116R
Device
RJ-45
Media Types:
- 10BASE-T
- 100BASE-TX
- 1000BASE-T
MAC Interface
- RGMII
88E1116R Device used in Copper Application
