IDT7207L30LB Overview

32K X 9 OTHER FIFO, 15 ns, PQCC32

IDT7207L30LB Parametric

Parameter Name	Attribute value
Number of functions	1
Number of terminals	32
Maximum operating temperature	70 Cel
Minimum operating temperature	0.0 Cel
Maximum supply/operating voltage	5.5 V
Minimum supply/operating voltage	4.5 V
Rated supply voltage	5 V
maximum access time	15 ns
Processing package description	Plastic, LCC-32
state	ACTIVE
Craftsmanship	CMOS
packaging shape	Rectangle
Package Size	ChipCARRIER
surface mount	Yes
Terminal form	J BEND
Terminal spacing	1.27 mm
terminal coating	tin lead
Terminal location	Four
Packaging Materials	Plastic/Epoxy
Temperature level	COMMERCIAL
memory width	9
organize	32K × 9
storage density	294912 deg
operating mode	ASYNCHRONOUS
Number of digits	32768 words
Number of digits	32K
cycle	25 ns
Memory IC type	Other first in first out

Preview

Download Datasheet

View All

CMOS ASYNCHRONOUS FIFO

32,768 x 9

Integrated Device Technology, Inc.

IDT7207

FEATURES:

• 32768 x 9 storage capacity

• High-speed: 15ns access time

• Low power consumption

— Active: 660mW (max.)

— Power-down: 44mW (max.)

• Asynchronous and simultaneous read and write

• Fully expandable in both word depth and width

• Pin and functionally compatible with IDT720x family

• Status Flags: Empty, Half-Full, Full

• Retransmit capability

• High-performance CMOS technology

• Military product compliant to MIL-STD-883, Class B

• Industrial temperature range (-40

C to +85

C) is avail-

able, tested to military electrical specifications

DESCRIPTION:

The IDT7207 is a monolithic dual-port memory buffer with

internal pointers that load and empty data on a first-in/first-out

basis. The device uses Full and Empty flags to prevent data

overflow and underflow and expansion logic to allow for

unlimited expansion capability in both word size and depth.

Data is toggled in and out of the device through the use of

the Write ( ) and Read ( ) pins.

The devices 9-bit width provides a bit for a control or parity

at the user’s option. It also features a Retransmit ( ) capa-

bility that allows the read pointer to be reset to its initial position

when

is pulsed LOW. A Half-Full Flag is available in the

single device and width expansion modes.

The IDT7207 is fabricated using IDT’s high-speed CMOS

technology. It is designed for applications requiring asynchro-

nous and simultaneous read/writes in multiprocessing, rate

buffering, and other applications.

Military grade product is manufactured in compliance with

the latest revision of MIL-STD-883, Class B.

FUNCTIONAL BLOCK DIAGRAM

WRITE

CONTROL

DATA INPUTS

–D

)

WRITE

POINTER

RAM ARRAY

32,768 x 9

READ

POINTER

THREE-

STATE

BUFFERS

DATA OUTPUTS

–Q

)

READ

CONTROL

RESET

LOGIC

FLAG

LOGIC

FL RT

EXPANSION

LOGIC

XO HF

3140 drw 01

The IDT logo is a registered trademark of Integrated Device Techology, Inc.

MILITARY AND COMMERCIAL TEMPERATURE RANGES

Integrated Device Technology, Inc.

For latest information contact IDT's web site at www.idt.com or fax-on-demand at 408-492-8391.

DECEMBER 1996

DSC-3140/2

5.05
