DF3A5.6FU
TOSHIBA Diodes for Protecting against ESD Epitaxial Planar Type
DF3A5.6FU
Diodes for Protecting against ESD
Unit: mm
•
•
The mounting of two devices on an ultra-compact package allows the
number of parts and the mounting cost to be reduced.
The zener voltage corresponds to the E24 Series.
Maximum Ratings
(Ta = 25°C)
Characteristics
Power dissipation
Junction temperature
Storage temperature range
Symbol
P
T
j
T
stg
Rating
100
125
−55~125
Unit
mW
°C
°C
JEDEC
JEITA
TOSHIBA
―
―
1-2P1A
Electrical Characteristics
(Ta = 25°C)
Characteristics
Zener voltage
Dynamic impedance
Reverse current
Terminal capacitance
(between Cathode and Anode)
Symbol
V
Z
Z
Z
I
R
C
T
I
Z
=
5 mA
I
Z
=
5 mA
V
R
=
2.5 V
V
R
= 0, f = 1 MHz
Test Condition
Weight: 0.006 g (typ.)
Min
5.3
⎯
⎯
―
Typ.
5.6
⎯
⎯
65
Max
6.0
40
1.0
―
Unit
V
Ω
µA
pF
Guaranteed Level of ESD Immunity
Test Condition
IEC61000-4-2
(Contact discharge)
ESD Immunity Level
±30 kV
Criterion: No damage to device elements
Marking
Equivalent Circuit
(top view)
5.6
1
2004-09-06
DF3A5.6FU
