QPL POWER INDUCTORS - SURFACE MOUNT
MLP5025
M27/367 Ferrite Core
TRADITIONAL
Pb
Wirewound, Molded, MIL-PRF-27
MIL
DASH
NUMBER
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
DCR
OHMS
MAX
CURRENT
RATING
A DC
7.00
6.75
6.50
6.25
6.00
5.80
5.70
5.60
5.50
4.69
4.45
4.34
3.70
3.41
3.23
3.07
2.90
2.79
2.61
2.51
2.36
2.24
2.11
1.82
1.61
1.48
1.33
1.12
1.04
1.00
PART
NUMBER
MLP5025-220L
MLP5025-270L
MLP5025-330L
MLP5025-390L
MLP5025-470L
MLP5025-560L
MLP5025-680L
MLP5025-820L
MLP5025-101L
MLP5025-121L
MLP5025-151L
MLP5025-181L
MLP5025-221L
MLP5025-271L
MLP5025-331L
MLP5025-391L
MLP5025-471L
MLP5025-561L
MLP5025-681L
MLP5025-821L
MLP5025-102L
MLP5025-122L
MLP5025-152L
MLP5025-182L
MLP5025-222L
MLP5025-272L
MLP5025-332L
MLP5025-392L
MLP5025-472L
MLP5025-562L
L µH
@1 kHz *
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
INC I
A DC
7.00
6.75
6.50
6.25
6.00
5.80
5.70
5.60
5.50
4.69
4.45
4.34
3.70
3.41
3.23
3.07
2.90
2.79
2.61
2.51
2.36
2.24
2.11
1.82
1.61
1.48
1.33
1.12
1.04
1.00
continued next page
0.0080
0.0085
0.0090
0.0095
0.0100
0.0105
0.0110
0.0120
0.0130
0.0180
0.0200
0.0210
0.0290
0.0340
0.0380
0.0420
0.0470
0.0510
0.0580
0.0630
0.0710
0.0790
0.0890
0.1190
0.1520
0.1790
0.2220
MARKING: M27/367-XX (MIL DASH NO.)
0.3150
MLP5025-XXXL (GOWANDA DASH NO.)
YYWWL (DATE CODE & LOT SYMBOL)
0.3620
24226 (GOWANDA CAGE CODE)
0.3970
0.490/0.520
(12.45/13.21)
M27/367 FERRITE CORE
All part numbers provide 15% tolerance on inductance
* Measured at 1 V ac open circuit with no dc current at 1 kHz
0.230/0.250
(5.84/6.35)
0.210/0.230
(5.33/5.84)
OVER TERMINAL
0.120 (3.04)
REF
0.055/0.075
(1.40/1.91)
0.050 (1.27) MIN TYP
NOTES:
• Operating Temperature Range:
-55°C to +130°C
RECOMMENDED FOOT PRINT
MARKING: M27/367-XX (MIL DASH NO.)
MLP5025-XXXL (GOWANDA DASH NO.)
YYWWL (DATE CODE & LOT SYMBOL)
24226 (GOWANDA CAGE CODE)
0.490/0.520
(12.45/13.21)
0.230/0.250
(5.84/6.35)
0.210/0.230
(5.33/5.84)
OVER TERMINAL
0.130 (3.30)
0.165
(4.19)
• Current Rating is based on a 45°C temperature
rise at an ambient temperature of 85°C
• Incremental Current is the approximate value
that will cause a 5% maximum decrease
in inductance at a zero dc current
• DWV 1000 Vrms @ Sea Level
500 Vrms @ 70,000 Feet
• Grade 5, encapsulated
• Weight maximum 1.5 grams
0.440
(11.18)
0.120 (3.04)
REF
0.055/0.075
(1.40/1.91)
TAPE AND REEL SPECS:
0.050 (1.27) MIN TYP
in. (mm)
RECOMMENDED FOOT PRINT
0.130 (3.30)
0.165
(4.19)
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
800
12 mm
24 mm
13 in.
0.440
(11.18)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
041614
www.gowanda.com
QPL POWER INDUCTORS - SURFACE MOUNT
continued from previous page
MLP5025
M27/367 Ferrite Core
Continued
PART
NUMBER
MLP5025-682L
MLP5025-822L
MLP5025-103L
MLP5025-123L
MLP5025-153L
MLP5025-183L
MLP5025-223L
MLP5025-273L
MLP5025-333L
MLP5025-393L
MLP5025-473L
MLP5025-563L
MLP5025-683L
MLP5025-823L
MLP5025-104L
MLP5025-124L
MLP5025-154L
MLP5025-184L
MLP5025-224L
MLP5025-274L
MLP5025-334L
MLP5025-394L
MLP5025-474L
MLP5025-564L
MLP5025-684L
MLP5025-824L
MLP5025-105L
MLP5025-125L
MLP5025-155L
MLP5025-185L
MLP5025-225L
TRADITIONAL
Pb
Wirewound, Molded, MIL-PRF-27
MIL
DASH
NUMBER
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
DCR
OHMS
MAX
CURRENT
RATING
A DC
0.970
0.810
0.760
0.730
0.630
0.530
0.500
0.470
0.390
0.380
0.350
0.330
0.300
0.260
0.240
0.200
0.178
0.157
0.141
0.131
0.126
0.110
0.103
0.100
0.080
0.077
0.071
0.065
0.061
0.052
0.050
L µH
@1 kHz *
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
22000
INC I
A DC
0.970
0.810
0.760
0.730
0.630
0.530
0.500
0.470
0.390
0.380
0.350
0.330
0.300
0.260
0.240
0.200
0.178
0.157
0.141
0.131
0.126
0.110
0.103
0.100
0.080
0.077
0.071
0.065
0.061
0.052
0.050
M27/367 FERRITE CORE
0.418
0.604
0.672
0.735
0.998
1.37
1.58
1.77
2.51
2.73
3.25
3.75
4.31
6.04
6.90
10.0
12.5
16.0
20.0
23.0
25.0
33.0
37.0
40.0
62.0
66.0
74.0
93.0
MARKING: M27/367-XX (MIL DASH NO.)
MLP5025-XXXL
105.0
(GOWANDA DASH NO.)
YYWWL (DATE CODE & LOT SYMBOL)
143.0
24226 (GOWANDA CAGE CODE)
160.0
0.230/0.250
0.490/0.520
(12.45/13.21)
(5.84/6.35)
0.210/0.230
(5.33/5.84)
OVER TERMINAL
All part numbers provide 15% tolerance on inductance
* Measured at 1 V ac open circuit with no dc current at 1 kHz
0.120 (3.04)
REF
0.055/0.075
(1.40/1.91)
0.050 (1.27) MIN TYP
NOTES:
• Operating Temperature Range:
-55°C to +130°C
• Current Rating is based on a 45°C temperature
rise at an ambient temperature of 85°C
MARKING: M27/367-XX (MIL DASH NO.)
MLP5025-XXXL (GOWANDA DASH NO.)
YYWWL (DATE CODE & LOT SYMBOL)
24226 (GOWANDA CAGE CODE)
0.490/0.520
(12.45/13.21)
0.230/0.250
(5.84/6.35)
0.210/0.230
(5.33/5.84)
OVER TERMINAL
RECOMMENDED FOOT PRINT
0.130 (3.30)
0.165
(4.19)
• Incremental Current is the approximate value
that will cause a 5% maximum decrease
in inductance at a zero dc current
• DWV 1000 Vrms @ Sea Level
500 Vrms @ 70,000 Feet
0.440
(11.18)
• Grade 5, encapsulated
• Weight maximum 1.5 grams
0.120 (3.04)
REF
0.055/0.075
(1.40/1.91)
TAPE AND REEL SPECS:
0.050 (1.27) MIN TYP
in. (mm)
RECOMMENDED FOOT PRINT
0.130 (3.30)
0.165
(4.19)
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
800
12 mm
24 mm
13 in.
0.440
(11.18)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
041614
www.gowanda.com
