3157-101-55004: DescriptionRESISTOR, TEMPERATURE DEPENDENT, NTC, 100ohm, SURFACE MOUNT, CHIP, 0805, ROHS COMPLIANT; CategoryPassive components The resistor; File Size114KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

3157-101-55004 Overview

RESISTOR, TEMPERATURE DEPENDENT, NTC, 100ohm, SURFACE MOUNT, CHIP, 0805, ROHS COMPLIANT

3157-101-55004 Parametric

Parameter Name	Attribute value
Objectid	1663127869
package instruction	CHIP, 0805, ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
YTEOL	0
Manufacturer's serial number	3157
Installation features	SURFACE MOUNT
Number of terminals	2
Package shape	RECTANGULAR PACKAGE
Rated power dissipation(P)	0.3 W
resistance	100 Ω
Resistor type	NTC THERMISTOR
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Thermistor Applications	TEMPERATURE SENSING
Tolerance	5%

Preview

Download Datasheet

View All

C orporate Hom e

|

Electronic Components

|

Se gm e nts

|

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

>

Products

>

By Type

>

Resistors

>

Product Feature Selector

> Product Details

3157-101-55004 Product Details

Live Product Chat

Sensing Resistors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

3157-101-55004

(1624327-1)

T E I nternal N umber: 1 6 2 4 3 2 7 - 1

Product Highlights:

l

3157 Series

l

Resistance = 100 ?

l

Tolerance = 5 %

l

Negative Temperature C oefficient

l

Power Rating = .30 W

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Obsolete

C ontact Product Information C enter

Buy P roduc t

Documentation & Additional Information

Product Drawings:

l

None Available

Catalog Pages/Data Sheets:

l

Thermistors For Surface Mount - Type 8158 Series - T...

(PDF, English)

Product Specifications:

l

None Available

Application Specifications:

l

None Available

Instruction Sheets:

l

None Available

CAD Files:

l

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

l

Resistance (?)

= 100

Electrical Characteristics:

l

Tolerance (%)

= 5

l

Power Rating (W) = 0.30

Body Related Features:

l

Series

= 3157

l

Packaging Style = 0805

l

Mount Style = Surface Mount

Contact Related Features:

l

Mode of Operation

= Negative Temperature C oefficient

Industry Standards:

l

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

l

Lead Free Solder Processes

= Reflow solder capable to 245?C ,

Reflow solder capable to 260?C

l

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Other:

l

Brand = C itec

Additional Information:

l

Product Line Information

3157-101-55004 Related Products

	3157-101-55004	1624327-1
Description	RESISTOR, TEMPERATURE DEPENDENT, NTC, 100ohm, SURFACE MOUNT, CHIP, 0805, ROHS COMPLIANT	RESISTOR, TEMPERATURE DEPENDENT, NTC, 100ohm, SURFACE MOUNT, CHIP, 0805, ROHS COMPLIANT
Objectid	1663127869	1663127810
package instruction	CHIP, 0805, ROHS COMPLIANT	CHIP, 0805, ROHS COMPLIANT
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
Manufacturer's serial number	3157	3157
Installation features	SURFACE MOUNT	SURFACE MOUNT
Number of terminals	2	2
Package shape	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
Rated power dissipation(P)	0.3 W	0.3 W
resistance	100 Ω	100 Ω
Resistor type	NTC THERMISTOR	NTC THERMISTOR
surface mount	YES	YES
Terminal location	DUAL ENDED	DUAL ENDED
Terminal shape	WRAPAROUND	WRAPAROUND
Thermistor Applications	TEMPERATURE SENSING	TEMPERATURE SENSING
Tolerance	5%	5%
