INTERCONNECTS
SERIES 450, 460, 470, 480 • 2,54 GRID SOLDER TAIL •
DOUBLE ROW STRIPS
Number of Pins X 2,54 /2
•
Series 450, 460, 470 & 480 double row header
5,08
2,54
2,54
strips come in various styles (pin, slotted,
head, turret and solder cup) with pluggable
solder tails
450...001 uses pin #0290
460...001 uses pin #0282
470...001 uses pin #0700
480...001 uses pin #8000
See pages 215 and 216 for details
2,54
0,64 DIA.
1,83 DIA.
4,22
4,75
2,79
0,46 DIA.
3,4
3,96
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
FIG. 1
2,54
2,54
2,79
0,46 DIA.
0,89
1,83
3,2
3,4
ORDERING INFORMATION
Series 450...001
0,64 / 0,46 Dia. Solder Tails
450-XX-2_ _-00-001000
Specify number of pins
04-64
FIG. 1
Series 460...001
3,96
Slotted Head / Solder Tail
460-10-2_ _-00-001000
FIG. 2
2,54
1,35 DIA.
0,81 DIA.
1,83 DIA.
2,79
2,54
3,23
FIG. 2
Series 470...001
Specify number of pins
02-64
Turret / Solder Tail
470-XX-2_ _-00-001000
FIG. 3
Series 480...001
3,4
Specify number of pins
04-64
0,51 DIA.
3,96
Solder Cup / Solder Tail
480-10-2_ _-00-001000
FIG. 4
FIG. 3
0,99 DIA.
Specify number of pins
02-64
1,83 DIA.
2,79
3,23
3,15
0,51 DIA.
4,22
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
10
0,25μm Au
For
Electrical, Mechanical
& Enviromental Data,
See page 264
2,54
FIG. 4
SPECIFY PLATING CODE XX=
Pin Plating
90
5,08μm Sn/Pb
40
5,08μm Sn
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 85 | INTERCONNECTS
