Rocker Switches
611/621-Series
The miniature 611/621-Series switches
are double insulated and available in
single or double pole. These snap-in
mounting style switches are available
with paddle, rocker or Visi-Rocker type
actuators. A variety of terminations are
offered with ratings through 11 amps.
International approvals are also
available.
Specifications
•Certifications*: UL, CSA, VDE, TUV,
SEMKO, DEMKO, SEV, NEMKO,
SETI
•Dielectric Strength: 1,000V (minimum)
•Insulation Resistance: 100 Megohms
(minimum)
•Base Material: Nylon
•Actuator Material: Nylon
* Due to ongoing technological advances, consult factory for
certification specifics.
.171[4.34]
Dimensional Specifications: in. [mm]
.825[20.95]
.080[2.03]
.125[3.18]
.590[14.98]
.380[9.65]
END
.250[6.35]
.207[5.26]
CENTER
.062[1.57]
DIA MIN
.046[1.17]
x
.029[.736]
.200[5.08]
.185[4.70]
.080[2.03] X .047[1.19] SLOT
.080 SOLDER LUG
(terminal option 1) functions 2,3,6,7,8
.877[22.27]
.892[22.66]
P.C.
(option 2)
.120[3.05]
DIA
.315[8.00]
PC TERMINAL FRONT MOUNT & MOUNTING PATTERN
(terminal option 2) functions 2,3,6,7,8
TERMINAL TYPE
.187[4.74] X
.032[.812]
3
.677[17.20]
HIGH
BARRIER
OPTION
.350[8.89]
.062[1.52]
DIA
.843[21.41]
.080 SOLDER LUG
.505[12.83]
.540
[13.72]
.825[20.95]
.590[14.98]
.380[9.65]
.187 TAB (Q.C)
(terminal option 9)
functions 1,2
.730[18.54]
1.040[26.42]
.920[23.36]
.187 SOLDER LUG
(terminal option 6)
functions 1,2
.250[6.35]
.046[1.17]
x
.032[.812]
.270[6.86]
PC TERMINAL FRONT/BACK MOUNT
& MOUNTING PATTERN
(terminal option 7,8) functions 1,2
+.000[.00]
-.004[.10]
TAB
.507[12.88]
P.C. (option 7,8)
PADDLE
.465[11.81]
PANEL
X
Y
THICKNESS
.030[.762]-.060[1.52] .508[12.90] .756[19.20]
.060[1.52]-.093[2.36] .508[12.90] .764[19.40]
.093[2.36]-.156[3.96] .508[12.90] .780[19.81]
Y
+.004[.10]
-.000[.00]
X
TEST CUT
HOLE IN
ACTUAL
MATERIAL
6
SERIES
6
ACTUATOR STYLE
11
PADDLE
21
CURVED ROCKER
21
1
5
ACTUATOR
BLACK
WHITE
BLACK
WHITE
9
1
2
1
9
-
1
2
3
4
6
7
8
9
0
-
9
-
V
INK
TRANSFER
STAMP
6
BASE/ACTUATOR
COLOR
1
BASE
BLACK
BLACK
WHITE
WHITE
RATING
2
.4VA MAX @20V
MAX (AC/DC)
2A 250VAC
5A 125VAC
RESISTIVE
11A 125VAC H
3
4A 250 VAC
8A 125VAC
4A 250VAC
8A 125VAC
INDUCTIVE
6(4)A 250VAC T85
8
TERMINATION
4
.080 SOLDER LUG
PC TERM
WIRE LEAD
7
WIRE LEAD
.187 SOLDER LUG
PC BACK MOUNT
PC FRONT MOUNT
.187TAB (QC)
ROCKER FACE
LEGEND
MOLDED-IN
5
1
2
4
5
3
4
9
POLES
1
2
5
6
SINGLE POLE
DOUBLE POLE
DOUBLE POLE W/
HIGH BARRIERS
SINGLE POLE W/
HIGH BARRIERS
EPOXY SEALED
TERMINALS
E
0
EPOXY
NONE REQUIRED
FUNCTION
1
2
3
6
7
8
ON-NONE-OFF
ON-NONE-ON
ON-NONE-(ON)
ON-OFF-ON
ON-OFF-(ON)
(ON)-OFF-(ON)
0
NO LEGEND
ON-OFF
(VERTICAL)
ON-OFF
(HORIZONTAL)
8
I-O
(HORIZONTAL)
9
I-O
(VERTICAL)
q
(indicates ON)
(ON ROCKER
RADIUS)
0
A
B
D
E
F
NOTES:
Shading indicates standard configurations.
Panel Cut-Out Recommendations: For sheet metal panels, switch must enter panel in same direction as the punch. (Burr on bottom.) Test cut hole in actual material.
N
1
Matte finish is standard. Custom colors are available. Consult factory.
2
Rating 1 contact surfaces: gold plate over nickel plate. Rating Code 9 available with function 1 or 2 only.
B
3
Available in single pole with high barriers, ON-NONE-OFF circuit with .187TAB terminals only.
V
4
Terminations 1, 2 and 3 are not available with function 1. Terminations 4, 6, 7 , 8 and 9 are available with function 1 or 2 only.
5
Molded-in Legend available only with Visi-Rocker Option.
W
6
White is standard with dark actuators; black is standard with light actuators.
7
Termination 3 available with rating 2 only - 18 gauge wire used.
8
Rating 9 using Termination 1 or 2 is rated T55 only.
COLOR OF MOLDED-
IN LEGEND AND/OR
VISI-ROCKER END
1
NOT APPLICABLE
BLACK
VISI-RED
WHITE
Carlingswitch,Inc. (860) 793-9281• Carlingswitch, LTD. Int + 44 1392-364422 • Carlingswitch Asia-Pacific, LTD. Int + 852-2737-2277
