IL7101N Overview

EARTH LEAKAGE CURRENT DETECTOR

Preview

Download Datasheet

View All

TECHNICAL DATA

IL7101N

EARTH LEAKAGE

CURRENT DETECTOR

Description

The IL7101N is designed for use in earth leakage circuit

interrupters for operation directly oft the AC Line in breakers.

It contains pre regulator, main regulator, after regulator,

differential amplifier, level comparator, latch circuit. The input

in the differential amplifier is connect to the secondary node of

zero current transformer. The level comparator generates high

level when earth leakage current is greater than some level.

N SUFFIX

PLASTIC

Pin Configuration

(Top

View)

Feature

• Low Power Consumption (P

=5mW) 100V/200V

• 100V/200V Common Built-in Voltage Regulator

• High Gain Differential Amplifier

• High Input Sensitivity

• Minimum External Parts

• Large Surge Margin

• Wide Operating Temperature Range (T

=-30 to 85°C)

• High Noise Immunity

Absolute Maximum

(T^ 2 ° )

Supply Voltage

Ratings

20V

8mA

200m W

- 30 to 85°C

- 55 to 125°C

Supply Current

Power Dissipation

Operating Temperature

Storage Temperature

Block Diagram
