FUSES
Non resettable fuses
Surface Mount
Fuse
Type MGA
super-quick-acting FF
Typical Time to Trip at 23˚C
MGA
1:1
50
75
100
Approvals, Patents
UL
recognition 200mA–5A
US 5.032.817
US 5.040.284
US 5.097.245
US 5.122.774
US 5.131.137
US 5.155.462
US 5.224.261
US 5.272.804
CSA acceptance 200mA–5A
US 4.749.980
US 4.860.437
US 4.926.543
US 5.001.451
US 5.027.101
Pre-arcing time in seconds t
s
• Standard 1206 SMD
• ‘‘Flip chip’’ design mounts
on any side
• Lowest resistance
• Hermetically sealed for
operating temperatures in
excess of 150 °C
• Low energy let-through
• Superior cycling
Percent of rated current I
n
Patents in US. and in further countries
Pre-arcing time/current
characteristic (at T
a
23 °C)
Rated
current I
n
Standards
UL 248-14 (formerly 198.G)
CSA C22.2 No. 248.14 (formerly 59.2 M)
n · I
n
1 · I
n
≥
4h
2,5 · I
n
≤
5s
200 mA–5 A
Standard 1206 SMD package size
Recommended (IGC 127-4)
3.05
1.52
1.52
Solder pads for wave soldering
Note: dimensions are in mm
0.5
Solder pads for reflow soldering
0.25
2.5
2.5
0.3
Technical data
Rated current
Time current characteristic
Interrupt capacity
Ambient temperature max.
Climatic category
Solderability
Soldering heat resistance
Material: Housing
Terminals
Packaging
see chart
super-quick-acting
50 A AC/DC
+ 150 °C
hermetically sealed
reflow: 260 °C / 30 sec. max;
wave 260 °C / 10 sec. max.
60 seconds above 200 °C, max. 260 °C
ceramic
nickel, tin-lead coated
8 mm tape and reel per EIA-RS481
(equivalent to IEC 60286-3)
2.0
2.3
46
www.schurterinc.com
FUSES
Non resettable fuses
Order No.
Rated current I
n
Rated voltage U
n
Breaking capacity
Voltage drop
Pu at 1· 5u mw
at I
n
mA / A / V ~
200 mA / 125 V
250 mA / 125 V
375 mA / 125 V
500 mA / 125 V
750 mA / 125 V
1
A / 125 V
1,5
A / 125 V
2
A / 125 V
2,5
A / 125 V
3
A / 125 V
4
A / 63 V
5
A / 32 V
at I
n
A~
AC / DC
typ.
mV
202
176
140
126
118
114
123
117
115
112
110
90
A
2
s
40
44
52
68
88
114
185
234
288
336
440
450
0,0013
0,0027
0,0039
0,0066
0,015
0,042
0,12
0,20
0,35
0,55
0,85
1,0
at 4 · I
n
typ.
Pre-arcing
l
2
t /
Packaging
Order No. Suffix
MGA
3410.0021.XX
3410.0022.XX
3410.0025.XX
3410 0027.XX
3410.0029.XX
3410.0031.XX
3410.0033.XX
3410.0035.XX
3410.0036.XX
3410.0037.XX
3410.0240.XX
3410.0141.XX
100 pieces taped & bagged:
.XX = .01
50 A / 125 V AC/DC
750 pieces taped & reeled:
.XX = .02
3000 pieces taped & reeled:
.XX = .03
10000 pieces taped & reeled:
.XX = .04
50 A / 63 V AC/DC
50 A / 32 V AC/DC
same as above /
wie oben
All ratings measured at ambient temperature 25 °C +/–3 °C
AC with unity power factor. DC with time constant less than 1 msec.
www.schurterinc.com
47
