A Global Leader in the Design, Development, and
Manufacture of Sensor and Magnetic Components
Series Datasheet – MK11(B) Reed Sensors
www.standexmeder.com
MK11(B) Series
Reed Sensors
Features: Cylindrical Reed Sensor, Choice of Cable Termination & Lengths available, Various Case Sizes
Applications: Door & Window Contacts, Safety Control, Position Sensing
Markets: Appliance, Industrial, Security & Others
Part Description:
MK 11/B0-0X00X-000X
Thread
M6 - M12
B = Brass Thread
Contact Contact
QTY
Form
1
A, B, C
Switch
Model
66, 85, 90
Magnetic
Sensitivity
C, D, E
Cable Length
(mm)
Termination
W
200, 300, 500, 1,000,
1,500, 2,000, 3,000, 5,000
Switch Model
66
10
200
0.5
1.0
150
0.25
0.7
0.05
10
10
0.3
85
100
1,000
1
2.5
150
1.5
1.1
0.05
10
10
0.5
90
10
175
0.5
1.0
150
0.2
0.7
1.5
10
9
1.5
Customer Options
Contact Data
Rated Power (max.)
Any DC combination of V&A not to exceed their individual max.’s
Unit
W
V
A
A
mOhm
kVDC
ms
ms
Ohm
pF
Switching Voltage (max.)
DC or peak AC
Switching Current (max.)
DC or peak AC
Carry Current (max.)
DC or peak AC
Contact Resistance (max.)
@ 0.5V & 50mA
Breakdown Voltage (min.)
According to EN60255-5
Operating Time (max.)
Incl. Bounce; Measured with w/ Nominal Voltage
Release Time (max.)
Measured with no Coil Excitation
Insulation Resistance (typ.)
Rh<45%, 100V Test Voltage
Capacitance (typ.)
@ 10kHz across open Switch
USA:
Europe:
Asia:
+1.866.782.6339
+49.7731.8399.0
+86.21.37820625
│
salesusa@standexmeder.com
│ info@standexmeder.com
│ salesasia@standexmeder.com
Version 01
27.01.2015
Modifications in the sense of technical progress are reserved.
A Global Leader in the Design, Development, and
Manufacture of Sensor and Magnetic Components
Series Datasheet – MK11(B) Reed Sensors
Housing and Cable Specifications
Housing Material
Case Color
Sealing Compound
Cable Typ
Cable Material
Cross Section (mm²)
Brass
Brass
Polyurethan
Flat Cable/ Round Cable
PVC
2 x 0.14 - 0.25 / 3 x 0.14
www.standexmeder.com
MK11(B) Reed Sensor
Environmental Data
Shock Resistance (max.)
1/2 sine wave duration 11ms
Unit
50
20
-30 to 70
-5 to 70
-30 to 70
g
g
°C
°C
°C
Vibration Resistance (max.)
Operating Temperature
Cable not moved
Operating Temperature
Cable moved
Handling & Assembly Instructions
Max torque of nuts depends on thread size
M6 = 2Nm , M8 = 6Nm , M10 - M12 = 12Nm
Cable bending-radius is diameter x 15
Min. bending distance to housing is 5mm
Decrease switching distance by mounting on iron
Do not use magnetically inductive screws
Series resistor recommended for > 5m cable length
Storage Temperature
Glossary Contact Form
Form A
Form B
Form C
NO = Normally Open Contacts
SPST = Single Pole Single Throw
NC = Normally Closed Contacts
SPST = Single Pole Single Throw
Changeover
SPDT = Single Pole Double Throw
Glossary Magnetic Sensitivity
Sens.
AT
A
05-10
B
10-15
C
15-20
D
20-25
E
25-30
F
30-35
G
35-40
Life Test Data
*Load increase reduces life expectancy of Reed Switches
USA:
Europe:
Asia:
+1.866.782.6339
+49.7731.8399.0
+86.21.37820625
│
salesusa@standexmeder.com
│ info@standexmeder.com
│ salesasia@standexmeder.com
Version 01
27.01.2015
Modifications in the sense of technical progress are reserved.
