5962-9214701MSA datasheet, PDF

Datasheet> All Categories > logic> logic> 5962-9214701MSA

5962-9214701MSA: DescriptionBus Driver, ABT Series, 8-Func, 1-Bit, True Output, BICMOS, CDFP20,; Categorylogic logic; File Size1MB，24 Pages; Manufacturere2v technologies

Download Datasheet Parametric Compare View All

5962-9214701MSA Overview

Bus Driver, ABT Series, 8-Func, 1-Bit, True Output, BICMOS, CDFP20,

5962-9214701MSA Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
package instruction	DFP, FL20,.3
Reach Compliance Code	compliant
Control type	ENABLE LOW
series	ABT
JESD-30 code	R-GDFP-F20
JESD-609 code	e0
length	13.09 mm
Logic integrated circuit type	BUS DRIVER
MaximumI(ol)	0.048 A
Number of digits	1
Number of functions	8
Number of ports	2
Number of terminals	20
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output characteristics	3-STATE
Output polarity	TRUE
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DFP
Encapsulate equivalent code	FL20,.3
Package shape	RECTANGULAR
Package form	FLATPACK
Peak Reflow Temperature (Celsius)	NOT APPLICABLE
power supply	5 V
Prop。Delay @ Nom-Sup	5.3 ns
propagation delay (tpd)	5.3 ns
Certification status	Qualified
Filter level	38535Q/M;38534H;883B
Maximum seat height	2.54 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	BICMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb) - hot dipped
Terminal form	FLAT
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT APPLICABLE
width	6.92 mm
Base Number Matches	1
