Datasheet> All Categories > Discrete semiconductor> diode> JANTXV1N5623

Preview

JANTXV1N5623: DescriptionRectifier Diode, 1 Element, 1.5A, 1000V V(RRM), Silicon,; CategoryDiscrete semiconductor diode; File Size84KB，2 Pages; ManufacturerVOLTAGE MULTIPLIERS INC.; Websitehttp://www.voltagemultipliers.com/

Download Datasheet Parametric View All

JANTXV1N5623 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	JANTXV1N5623	-	-	View	Buy Now

JANTXV1N5623 Overview

Rectifier Diode, 1 Element, 1.5A, 1000V V(RRM), Silicon,

JANTXV1N5623 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	VOLTAGE MULTIPLIERS INC.
package instruction	E-LALF-W2
Reach Compliance Code	unknown
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.2 V
JESD-30 code	E-LALF-W2
JESD-609 code	e0
Maximum non-repetitive peak forward current	50 A
Number of components	1
Number of terminals	2
Maximum operating temperature	175 °C
Maximum output current	1.5 A
Package body material	GLASS
Package shape	ELLIPTICAL
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Guideline	MIL-19500/429
Maximum repetitive peak reverse voltage	1000 V
Maximum reverse recovery time	0.5 µs
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

200 V - 1,000 V Rectifiers

1.5 A Forward Current

150 ns - 500 ns Recovery Time

AXIAL LEADED

HERMETICALLY SEALED

MIL-PRF-19500/429

JAN

JANTX

JANTXV

1N5615 1N5617

1N5619 1N5621

1N5623

3

ELECTRICAL CHARACTERISTICS AND MAXIMUM RATINGS

Part

Working

Number Reverse

Voltage

(Vrwm)

Average

Rectified

Current

(Io)

Reverse

Current

@ Vrwm

(Ir)

Forward

Voltage

1 Cycle Repetitive Reverse

Surge

Recovery

Current

Time

tp=8.3ms

(3)

(Ifsm)

(Ifrm)

(Trr)

25°C

Amps

25°C

Amps

25°C

ns

Thermal

Impedance

Junction

Cap.

@50VDC

@ 1kHZ

(Cj)

25°C

pF

(Vf)

25°C

Volts

Amps

u

J-L

L=.125 L=.375 L=.500

°C/W

55°C(1) 100°C(2) 25°C 100°C

Volts

1N5615

1N5617

1N5619

1N5621

1N5623

Amps

µA

200

400

600

800

1000

1.50

0.75

0.5

25

1.6

3.00

25

6

150

250

300

500

18

38

45

16

(1)TL=55°C L=0.375" (2)TL=100°C L=0.375" (3)If=0.5A, Ir=1.0A, Irr=0.25A • Op.Temp.= -65°C to +175°C Stg.Temp.= -65°C to +200°C

.110(2.8)

.065(1.65)

.185(4.7)

MAX.

1.30(33.02)

.90(22.86)

.033(8.38)

.026(.66)

Dimensions: In. (mm) • All temperatures are ambient unless otherwise noted. • Data subject to change without notice.

VOLTAGE MULTIPLIERS INC.

8711 W. Roosevelt Ave.

Visalia, CA 93291

TEL

559-651-1402

FAX

559-651-0740

www.voltagemultipliers.com

59
