3-5223080-2 Product Details
Live Product Chat
Product View
2mm Centerline Futurebus+ Connectors
Always EU R oHS/ELV C om pliant
(
Sta te m e nt of C om pliance
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3-5223080-2
T E I nternal N umber: 3 - 5 2 2 3 0 8 0 - 2
Product Highlights:
l
Module Type = Signal
l
30 Signal Positions
l
Fixed-Board (Header)
l
Sequencing
l
Sequencing C onfiguration Row A = Mating Post Length
5.75mm, Termination Post Length 4.25mm, Mating Post
Length 5mm, Termination Post Length 4.25mm
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Obsolete
C ontact Product Information C enter
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
C onnector, Z-PAC K*, 2 mm FB, Signal and Power
(PDF, English)
Application Specifications:
l
Z-PAC K 2mm FB (Futurebus+) Receptacle and Pin Header...
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Fixed-Board (Header)
l
PC B Mount Angle
= Vertical
l
Post Type
= Press-Fit
l
C omment = With sequenced contacts. Refer to customer drawing for
specific loading patterns.
Mechanical Attachment:
l
Module Type
= Signal
l
Press-Fit Post Style = C ompliant Pin
l
Pin Header Width (mm [in]) = 18.00 [0.709]
Electrical Characteristics:
l
Voltage Rating (VAC ) = 30
Body Related Features:
l
Number of Signal Positions
= 30
l
Sequencing
= Yes
l
Sequencing C onfiguration Row A
= Mating Post Length 5.75mm,
Termination Post Length 4.25mm, Mating Post Length 5mm,
Termination Post Length 4.25mm
l
Sequencing C onfiguration Row B
= Mating Post Length 5.75mm,
Termination Post Length 4.25mm, Mating Post Length 5mm,
Termination Post Length 4.25mm
l
Sequencing C onfiguration Row C
= Mating Post Length 5.75mm,
Termination Post Length 4.25mm, Mating Post Length 5mm,
Termination Post Length 4.25mm
l
Sequencing C onfiguration Row D
= Mating Post Length 5.75mm,
Termination Post Length 4.25mm, Mating Post Length 5mm,
Termination Post Length 4.25mm
l
Sequencing C onfiguration Row E
= Mating Post Length 5.75mm,
Termination Post Length 4.25mm, Mating Post Length 5mm,
Termination Post Length 4.25mm
l
Number of Rows
= 5
l
Post Plating
= Tin
l
C enterline, Matrix (mm [in]) = 2.00 x 2.00 [.079 x .079]
Contact Related Features:
l
C ontact Base Material = Phosphor Bronze
l
C ontact Mating Area Plating Material = Gold (30)
Housing Related Features:
l
Housing Material = Liquid C rystal Polymer (LC P)
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
