ES1D-LTP: DescriptionRectifier Diode, 1 Element, 1A, 200V V(RRM), Silicon, DO-214AC, ROHS COMPLIANT, PLASTIC, SMA, 2 PIN; CategoryDiscrete semiconductor diode; File Size331KB，3 Pages; ManufacturerMicro Commercial Components (MCC); Environmental Compliance

Download Datasheet Parametric View All

ES1D-LTP Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ES1D-LTP	-	-	View	Buy Now

ES1D-LTP Overview

Rectifier Diode, 1 Element, 1A, 200V V(RRM), Silicon, DO-214AC, ROHS COMPLIANT, PLASTIC, SMA, 2 PIN

ES1D-LTP Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Micro Commercial Components (MCC)
Parts packaging code	DO-214AC
package instruction	R-PDSO-C2
Contacts	2
Reach Compliance Code	not_compliant
ECCN code	EAR99
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.95 V
JEDEC-95 code	DO-214AC
JESD-30 code	R-PDSO-C2
JESD-609 code	e3
Humidity sensitivity level	1
Maximum non-repetitive peak forward current	30 A
Number of components	1
Number of terminals	2
Maximum operating temperature	175 °C
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	200 V
Maximum reverse recovery time	0.035 µs
surface mount	YES
Terminal surface	Matte Tin (Sn)
Terminal form	C BEND
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

MCC

Features

Micro Commercial Components

omponents

20736

Marilla

Street Chatsworth

!"#

$ % !"#

ES1A-L

THRU

ES1J-L

1 Amp Super Fast

Recovery Rectifier

50 to 600

Volts

DO-214AC

(SMA) (LEAD

FRAME)

•

Lead

Finish/RoHS Compliant(Note 1) ("P" Suffix designates

Free

RoHS Compliant. See ordering information)

•

Epoxy meets

94 V-0 flammability rating

•

Moisture Sensitivity Level 1

•

Built-in strain relief

•

Super fast switching speed under 35ns

•

Marking : Cathode band and type number (No '-L' Suffix)

•

Halogen

free available upon request by adding suffix "-HF"

Maximum Ratings

•

Operating Temperature: -65 to +175

Storage Temperature: -65 to +175

Maximum Thermal Resistance:

35°C/W

Junction To Lead

85°C/W

Junction To

Ambient

MCC

Part Number

Electrical Characteristics @ 25°C Unless Otherwise Specified

Average Forward

Current

Peak Forward Surge

Current

Maximum

Instantaneous

Forward Voltage

ES1A-L-ES1D-L

ES1G-L

ES1J-L

Maximum DC

Reverse Current At

Rated DC Blocking

Voltage

Maximum Reverse

Recovery Time

Typical Junction

Capacitance

F(AV)

1.0A

125

ES1A-L

ES1B-L

ES1D-L

ES1G-L

ES1J-L

Maximum

Recurrent

Peak Reverse

Voltage

50V

100V

200V

400V

600V

Maximum

RMS Voltage

Maximum DC

Blocking

Voltage

35V

70V

140V

280V

420V

50V

100V

200V

400V

600V

DIMENSIONS

FSM

30A

8.3ms, half sine

.95V

1.25V

1.70V

5µA

80µA

= 1.0A;

DIM

INCHES

MIN

.079

.050

.002

---

.030

.065

.189

.157

.090

MAX

.096

.064

.008

.02

.060

.091

.220

.181

.115

MIN

2.00

1.27

.05

---

.76

1.65

4.80

4.00

2.25

MAX

2.44

1.63

.20

.51

1.52

2.32

5.59

4.60

2.92

NOTE

SUGGESTED SOLDER

PAD LAYOUT

0.090”

= 25

= 100

0.085”

35ns

15pF

=0.5A, I

=1.0A,

=0.25A

Measured at

1.0MHz, V

=4.0V

0.070”

Notes: 1.

High Temperature Solder Exemption Applied, see EU Directive Annex Notes 7.

Revision:

www.mccsemi.com

1 of 3

2015/02/06
