SMD Low Ohmic
–
Current Sense Resistors
Type RL73 Series
Key Features
Up to 2W @ 70°C
8 chip sizes
Ideal for current
detection
Terminal finish
–
electroplated 100% matte
Sn
Applications
Communications
Audio
Automotive
Low voltage power
supplies
Power management
applications
TE Connectivity are pleased to offer this thick film chip resistor for
current sensing positions. It has a special metal glaze resistive element
and a nickel barrier layer beneath the solder to prolong terminal life.
Following the developments by semiconductor manufacturers in the
production of a range of IC's for battery charge management and low
voltage power supplies, the RL73 Series satisfies the demand for a low
ohmic shunt resistor to act as a current sensor.
Electrical Characteristics Standard Power
Size
RL73X1H
RL73V1H
RL73N1H
RL73M1E
RL73N1E
RL73K1E
RL73V1J
RL73M1J
RL73N1J
RL73K1J
RL73V2A
RL73M2A
RL73N2A
RL73K2A
RL73H2A
Size
TCR
(PPM/°C)
±1000
±600
±300
±400
±300
±200
±600
±400
±300
±200
±600
±400
±300
±200
±100
Power
rating @
70°C
0.05W
Resistance
Range (Ω)
R10
–
R13
R15
–
R47
R51
–
R91
R05
–
R091
R10
–
R47
R51
–
R91
R020
–
R047
R051
–
R091
R10
–
R50
R51
–
R91
R020
–
R047
R051
–
R10
R11
–
R18
R20
–
R91
R10
–
R91
Max
Operating
Current
0.70A
Packaging
TDF
1000
TD
5000
TE
Tape
Paper
0201
0402
0.0625W
1.11A
1000
5000
Paper
0603
0.1W
2.23A
1000
5000
Paper
0805
0.125W
2.50A
1.11A
1000
5000
Paper
1773269 REV H 12/2018
Dimensions in
millimetres unless
otherwise specified
Dimensions Shown for
reference purposes only.
Specifications subject to
change
For Email, phone or live chat,
go to: www.te.com/help
SMD Low Ohmic
–
Current Sense Resistors
Electrical Characteristics Standard Power (continued)
Size
RL73V2B
RL73M2B
RL73N2B
RL73K2B
RL73H2B
RL73V2E
RL73M2E
RL73N2E
RL73K2E
RL73H2E
RL73V2H
RL73M2H
RL73N2H
RL73K2H
RL73H2H
RL73V3A
RL73M3A
RL73N3A
RL73K3A
RL73H3A
Size
TCR
(PPM/°C)
±600
±400
±300
±200
±100
±600
±400
±300
±200
±100
±600
±400
±300
±200
±100
±600
±400
±300
±200
±100
Power
rating @
70°C
Resistance
Range (Ω)
R010
–
R020
R022
–
R047
R051
–
R091
R10
–
R91
R10
–
R91
R010
–
R020
R022
–
R047
R051
–
R091
R10
–
R91
R075
–
R91
R010
–
R020
R022
–
R047
R051
–
R091
R10
–
R91
R050
–
R91
R010
–
R020
R022
–
R047
R051
–
R091
R10
–
R91
R020
–
R91
Max
Operating
Current
5.00A
1.58A
7.07A
2.58A
8.66A
3.87A
10.0A
7.07A
Packaging
TDF
TD
TE
Tape
1206
0.25W
1000
5000
Paper
1210
0.5W
1000
5000
Paper
2010
0.75W
4000
Embossed
Plastic
2512
1W
4000
Embossed
Plastic
Characteristics Electrical
–
High Power Version - RLP73
Max.
Operating
current
1.56A
Packaging
TDF
1000
TD
5000
TE
Tape
Paper
Type
RLP73M1E
RLP73N1E
RLP73K1E
RLP73M1J
RLP73N1J
RLP73K1J
RLP73M2A
RLP73N2A
RLP73K2A
RLP73V2B
RLP73M2B
RLP73N2B
RLP73K2B
Size
TCR
(PPM/°C)
±400
±300
±200
±400
±300
±200
±400
±300
±200
±600
±400
±300
±200
Power
rating
0.125W
Resistance
Range
R051
–
R091
R10
–
R47
R51
–
R91
R051
–
R091
R10– R47
R51
–
R91
R051
–
R091
R10
–
R47
R51
–
R91
R010
–
R020
R022
–
R047
R051
–
R091
R10
–
R91
0402
0603
0.125W
1.98A
1000
5000
Paper
0805
0.25W
2.21A
1000
5000
Paper
1206
0.5W
7.07
1000
5000
Paper
1773269 REV H 12/2018
Dimensions in
millimetres unless
otherwise specified
Dimensions Shown for
reference purposes only.
Specifications subject to
change
For Email, phone or live chat,
go to: www.te.com/help
SMD Low Ohmic
–
Current Sense Resistors
Characteristics Electrical
–
High Power Version - RLP73 (continued)
Type
RLP73V2E
RLP73M2E
RLP73N2E
RLP73K2E
RLP73V2H
RLP73M2H
RLP73N2H
RLP73K2H
RLP73V3A
RLP73M3A
RLP73N3A
RLP73K3A
Size
1210
TCR
(PPM/°C)
±600
±400
±300
±200
±600
±400
±300
±200
±600
±400
±300
±200
Power
rating
0.75W
Resistance
Range
R010
–
R020
R022
–
R047
R051
–
R091
R10
–
R91
R010
–
R020
R022
–
R047
R051
–
R091
R10
–
R91
R010
–
R020
R022
–
R047
R051
–
R091
R10
–
R91
Max.
Operating
current
8.66A
Packaging
TDF
1000
TD
5000
TE
Tape
Paper
2010
1W
10A
1000
4000
Embossed
Plastic
2512
2W
14.1A
1000
4000
Embossed
Plastic
Operating Voltage=√(P*R) ; Overload Voltage=2.5*√(P*R) ; Operating Current=√(P/R)
Maximum operating temperature -55°C to +155°C
Storage Temperature 25±3°C; Humidity < 80%RH
Power Derating curve
For resistors operated in ambient temperatures above 70°C, power rating must be derated in
accordance with this curve.
1773269 REV H 12/2018
Dimensions in
millimetres unless
otherwise specified
Dimensions Shown for
reference purposes only.
Specifications subject to
change
For Email, phone or live chat,
go to: www.te.com/help
SMD Low Ohmic
–
Current Sense Resistors
Construction and dimensions
Alumina Substrate
Bottom Electrode (Ag)
Top Electrode (Ag-Pd)
Edge Electrode (NiCr)
Barrier Layer (Ni)
External Electrode (Sn)
Resistor Layer (Ag/Pd)
Primary Overcoat (Glass)
Secondary Overcoat (Epoxy)
Type
RL73
RL73 /
RLP73
RL73 /
RLP73
RL73 /
RLP73
RL73 /
RLP73
RL73 /
RLP73
RL73 /
RLP73
RL73
RLP73
RLP73
Size
0201 (1H)
0402 (1E)
0603 (1J)
0805 (2A)
1206 (2B)
1210 (2E)
2010 (2H)
2512 (3A)
2512 (3A)
(R010-R099)
2512 (3A)
(R10 -R91)
L (mm)
0.60±0.03
1.00±0.05
1.60±0.10
2.00±0.10
3.10±0.10
3.10±0.10
5.00±0.10
6.35±0.10
6.35±0.20
6.35±0.20
W (mm)
0.30±0.03
0.50±0.05
0.80±0.10
1.25±0.10
1.55±0.10
2.60±0.15
2.50±0.15
3.10±0.15
3.15±0.15
3.15±0.15
T (mm)
0.23±0.05
0.32±0.10
0.45±0.10
0.55±0.10
0.55±0.10
0.55±0.10
0.60±0.15
0.60±0.10
0.74±0.10
0.74±0.10
D1 (mm)
0.12±0.05
0.25±0.10
0.30±0.20
0.30±0.20
0.50±0.30
0.50±0.30
0.60±0.30
0.60±0.30
0.60±0.30
0.60±0.30
D2 (mm)
0.15±0.05
0.20±0.10
0.30±0.20
0.40±0.25
0.40±0.25
0.50±0.25
0.50±0.25
0.55±0.25
0.55±0.25
2.10±0.10
Weight (g)
(1000 Pcs.)
0.18
0.7
1.99
5.3
8.82
15.5
27.03
43.08
53.08
53.08
Suggested PCB Layout Plan
Type
0201
0402
0603
0805
1206
1210
2010
2512 (1W)
2512 (2W)
≤99mΩ
2512 (2W)
≥100mΩ
A (mm)
0.25
0.50
0.80
1.00
2.00
2.00
3.60
4.90
4.90
1.0
B (mm)
0.30
0.50
1.00
1.00
1.15
1.15
1.40
1.60
1.60
3.55
C ±0.2mm
0.40
0.60
0.90
1.35
1.70
2.50
2.50
3.20
3.20
3.20
1773269 REV H 12/2018
Dimensions in
millimetres unless
otherwise specified
Dimensions Shown for
reference purposes only.
Specifications subject to
change
For Email, phone or live chat,
go to: www.te.com/help
SMD Low Ohmic
–
Current Sense Resistors
Solder Profile
(1) Time of IR reflow soldering at maximum temperature point 260°C：10s
(2) Time of wave soldering at maximum temperature point 260°C : 10s
(3) Time of soldering iron at maximum temperature point 410°C : 5s
Marking Specification
For 0201 and 0402 size resistor
–
No Marking
1% & 5% 0805/1206/1210/2010/2512 size Resistors
–
4 Digit Marking.
Example:
Resistance
Marking
47mΩ
R047
75mΩ
R075
15mΩ
R015
750mΩ
R750
820mΩ
R820
5% for 0603: 3 digits marking in E24
1% for 0603: 3 digits marking with under-line in E96 (if value appears in both E96 and E24 refer to
E24)
R10
243
047
3 digits marking for E24 or R value suffix is zero in E96: R10=100mΩ; R28=280mΩ
3 digits marking for E96: 243=243mΩ; 511=511mΩ
3 digit marking for E24 where value is less than 100mΩ and R value suffix is NOT 0;
E.G. R047=47mΩ
1773269 REV H 12/2018
Dimensions in
millimetres unless
otherwise specified
Dimensions Shown for
reference purposes only.
Specifications subject to
change
For Email, phone or live chat,
go to: www.te.com/help
