552744-4 Product Details
Live Product Chat
Product Photo
2.16 [.085] Printed Circuit Board Connectors
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
552744-4
T E I nternal N umber: 5 5 2 7 4 4 - 4
Product Highlights:
l
Receptacle
l
Number of Positions = 64
l
PC B Mount Style = Right Angle
l
Reverse Orientation
l
Standard Profile
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Gender
= Receptacle
l
Number of Positions
= 64
l
PC B Mount Style
= Right Angle
l
Orientation
= Reverse
l
Profile
= Standard
l
Shielded
= No
l
Mating C onnector Lock = With
l
Mating C onnector Lock Type = 4-40 Tapped Holes
l
PC B Retention Feature
= Yes
l
Grounded
= No
l
Panel Thickness (mm [in]) = 1.57 [0.062]
l
C olor = Black
l
Bracket Material = Thermoplastic
Mechanical Attachment:
l
Panel Attachment
= With
l
Panel Attachment Style = Rear Mount
l
Plate Material = Thermoplastic
l
C omb Material = Thermoplastic
Termination Related Features:
l
Solder Tail C ontact Plating = Tin
Body Related Features:
l
PC B Retention Method
= Mounting Holes
l
PC B Tail Length (mm [in]) = 4.75 [0.187]
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold
l
C ontact Base Material = C opper Alloy
Housing Related Features:
l
Housing Material = Thermoplastic
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Other:
l
Brand = AMP
