4100 Series
Toroidal Surface Mount Inductors
SELECTION GUIDE
Order Code
412R7C
414R7C
416R8C
41100C
41150C
41220C
41330C
41470C
41680C
41101C
41151C
41221C
41331C
Inductance
(0kHz, 0mV
AC
)
Nom.
μH
2.7
4.7
6.8
0
5
22
33
47
68
00
50
220
330
Inductance Range
(0kHz, 0mV
AC
)
Min. - Max.
μH
2. - 3.5
3.3 - 5.4
4.7 - 7.8
7.3 - 2.2
0.6 - 7.6
5.8 - 26.3
23.8 - 39.6
35.5 - 59.2
52.2 - 87.0
75.2 - 25
4 - 89
64 - 274
247 - 42
DC Current
Nom.
A
8.
6.7
5.7
4.7
4.0
3.3
2.7
2.2
.75
.47
.6
.03
0.83
DC Resistance
Max.
mΩ
4
8
20
24
28
33
38
62
0
58
247
377
462
FEATURES
n
compliant
RoHS
n
2.7μH to 330μH
n
Surface mount
n
J-STD-020C reflow (260ºC
pk
)
n
to 8.0A I
DC
Up
n
V-0 package materials
UL94
n
Compact size
n
Toroidal construction minimizes EMI
n
& place compatible
Pick
MECHANICAL DIMENSIONS
16.76 [0.660] Max.
Recommended Footprint Details
41330C
17.53 [0.690] Max.
DESCRIPTION
The 400 series is a range of surface mount
toroidal inductors designed for use in switching
power supplies and DC/DC converters. The parts
are ideal for applications requiring low profile
compact components in a surface mount package.
XYYWW
15.75 [0.620]
14.99 [0.590]
1.52 [0.060]
S
9.91 [0.390] Max.
x4 Places
0.60±0.15 [0.024±0.006]
0.127 [0.005]
15.58 [0.614]
14.01 [0.552]
All dimensions in mm [inches].
Package weight: 5.6g Typ.
10.10 [0.398]
ABSOLUTE MAXIMUM RATINGS
Operating free air temperature range
18.00 [0.709]
All dimensions in mm [inches]
Tube quantity: 25
Tube material: Antistatic coated clear PVC
Tube length: 475±2 [8.70±0.079]
-40°C to 85°C
-40°C to 25°C
Storage temperature range
All specifications typical at T
A
=25°C
Maximum DC current occurs when either the inductance falls to 75% of its nominal value or when its temperature rise reaches 40°C,
whichever is sooner.
RoHS COMPLIANCE INFORMATION
This series is compatible with RoHS soldering systems. Surface mount products can withstand
a peak temperature of 280°C. The pin termination finish on this product series is pure tin dip. All
types are backward compatible with Sn/Pb soldering systems.
For further information, please visit:
www.cd4power.com/rohs
C&D Technologies (NCL) Limited reserve the right to alter or improve the specification, internal design or manufacturing
process at any time, without notice. Please check with your supplier or visit our web site to ensure that you have the
current and complete specification for your product before use.
© C&D Technologies (NCL) Limited 2005 KMP_400C.
No part of this publication may be copied, transmitted or stored in a retrieval system or reproduced in any way including,
but not limited to, photography, photocopy, magnetic or other recording means, without prior written permission from
C&D Technologies (NCL) Limited. Instructions for use are available from www.cd4power.com
