597-3604-502F,507F
597-3324-502F,507F
597-3904-502F,507F
PART NUMBER
BLUE (470nm)
GREEN(527nm)
WHITE
LED COLOR
REV
A
ECN NO
REVISIONS
NEW RELEASE
DRN CKD APP
BP
NO
DATE
4-2-18
0.063
[1.6]
0.047
[1.2]
0.031
[0.8]
R 0.006
[0.15]
UNITS: mm
TOLERANCE (UNLESS OTHERWISE SPECIFIED): ±0.2mm
TAPING SPECIFICATIONS
0.022
[0.55]
0.007
[0.18]
ABSOLUTE MAXIMUM RATINGS AT 25 $ C
LED COLOR
0.06
[1.5]
0.031
[0.8]
BLUE (470nm)
WHITE
POWER
DISSIPATON
(mW)
66
70
66
FORWARD
CURRENT
(mA)
20
PEAK FORWARD
CURRENT
(mA)
100
REVERSE
VOLTAGE
(V)
5
OPERATING
TEMPRATURE
( $ C)
STORAGE
TEMPRATURE
( $ C)
GREEN (527nm)
-40 TO +100 -40 TO +100
0.026
[0.65]
1
2
LED COLOR
OPERATING CHARACTERISTICS AT 25 $ C
LUMINOUS
INTENSITY
(mcd)
IF (mA) MIN. TYP.
14
56
56
5
140
120
40
MAX.
330
220
56
MIN
520
DOMINANT
WAVELENGTH
(nm)
TYP.
470
527
MAX
535
REVERSE
CURRENT
MAX
10 µA @ VR=5V
FORWARD
VOLTAGE
IF=5mA
TYP.
2.9
3
2.9
MAX.
3.3
3.5
3.3
CATHODE MARK
GREEN (527nm)
WHITE
BLUE (470nm)
X=0.295
Y=0.280
RECOMMENDED RoHS SOLDER PROFILE
.096
[2,44 ]
.031
[0,8 ]
PIN 1
CATHODE
PIN 2
ANODE
LED SCHEMATIC
.031
[0,8 ]
.033
[0,85 ]
NOTES:
1. DIALIGHT P/N: 597-3XX4-502F, 597-3XX4-507F.
SUFFIX -502F FOR 20 PCS ON A SAMPLE TAPE STRIP
SUFFIX -507F FOR 7" DUANETER REEL, PACKAGED 3000 PCS PER REEL
2. LABELING FOR REEL AND OUTSIDE OF ALUMINUM BAG:
DIALIGHT P/N, QUANTITY PER REEL, DATE CODE, INTENSITY BIN CODE,
LOT NUMBER AND COUNTRY OF ORIGIN
3. TAPE AND REEL LEDS MAY REQUIRE RE-TAPING AFTER TWELVE MONTHS.
4. PIN NUMBERS ARE FOR REFERENCE ONLY, DESIGNATION NON-EXISTENT
ON PART.
5. THIS PRODUCT IS RoHS COMPLIANT. EACH BAG IS TO BE MARKED WITH RoHS
COMPLIANT LABEL OR EQUIVALENT MARKINGS. LED MUST BE Pb FREE.
6. MSL LEVEL 3
THIS DRAWING AND THE CONTENTS HEREIN ARE CONFIDENTIAL AND THE SOLE
PROPERTY OF DIALIGHT CORP. REPRODUCTION OF THIS DRAWING OR
CONSTRUCTION OF ANY PARTS WITHIN THIS DRAWING ARE FORBIDDEN WITHOUT
THE WRITTEN CONSENT OF DIALIGHT CORP.
SCALE: 50.000
DIALIGHT CORP INTERNAL REFERENCE ONLY = 3D MODEL :
DRAWING NUMBER
4500521848X15 -A.1
REV
ALL DIM'S IN: INCHES (MM)
TOLERANCES:
UNLESS OTHERWISE SPECIFIED
FRACTIONS:
DECIMALS (.XX):
# 1/64
TITLE
# .005
MATERIAL
# .01
RECOMMENDED SOLDER PAD LAYOUT
OBSERVE PRECAUTIONS FOR
HANDLING ELECTROSTATIC
SENSITIVE DEVICES
ATTENTION:
C-18367
SM LED 0603 PACKAGE
A
DECIMALS (.XXX):
ANGLES:
# 1 $
DECIMALS (.XXXX):
FINISH
# .0005
FSCM
83330
1501 ROUTE 34 SOUTH
FARMINGDALE, NJ 07727
(732) 919-3119
www.dialight.com
SHEET
1
OF
1
FAMILY TABLE:
