The ISO103 isolation amplifier provides both signal
and power across an isolation barrier. The ceramic
non-hermetic hybrid package with side-brazed pins
contains a transformer-coupled DC/DC converter and
a capacitor-coupled signal channel.
Extra power is available on the isolated input side for
external input conditioning circuitry. The converter is
protected from shorts to ground with an internal cur-
rent limit, and the soft-start feature limits the initial
currents from the power source. Multiple-channel syn-
chronization can be accomplished by applying a TTL
clock signal to paralleled Sync pins. The Enable con-
*Ground if not used
trol is used to turn off transformer drive while keeping
the signal channel demodulator active. This feature
provides a convenient way to reduce quiescent current
for low power applications.
The wide barrier pin spacing and internal insulation
allow for the generous 1500Vrms continuous rating.
Reliability is assured by 100% barrier breakdown
testing that conforms to UL1244 test methods. Low
barrier capacitance minimizes AC leakage currents.
These specifications and built-in features make the
ISO103 easy to use, as well as providing for compact
PC board layouts.
International Airport Industrial Park • Mailing Address: PO Box 11400, Tucson, AZ 85734 • Street Address: 6730 S. Tucson Blvd., Tucson, AZ 85706 • Tel: (520) 746-1111
NOTE: (1) Conforms to UL1244 test methods. 100% tested at 1500Vrms for 1 minute. (2) If using external synchronization with a TTL-level clock, frequency should
be between 1.2MHz and 2MHz with a duty-cycle greater than 25%.
®
ISO103
2
ABSOLUTE MAXIMUM RATINGS
Supply Without Damage ....................................................................
±18V
V
IN
, Sense Voltage .............................................................................
±50V
Com 1 to Gnd 1 or Com 2 to Gnd 2 ..............................................
±200mV
Enable, Sync ........................................................................... 0V to +V
CC2
Continuous Isolation Voltage ..................................................... 1500Vrms
Junction Temperature ...................................................................... 150°C
Storage Temperature ...................................................... –25°C to +125°C
Lead Temperature,10s .................................................................... 300°C
Output Short to Gnd 2 Duration ............................................... Continuous
±V
CC1
to Gnd 1 Duration .......................................................... Continuous
PIN CONFIGURATION
+V
C
+V
CC1
–V
CC1
1
2
3
24 Ps Gnd
23 Gnd 1
22 V
IN
21 Com 1
–V
CC1
4
ELECTROSTATIC
DISCHARGE SENSITIVITY
Any integrated circuit can be damaged by ESD. Burr-Brown
recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling
and installation procedures can cause damage.
ESD damage can range from subtle performance degrada-
tion to complete device failure. Precision integrated circuits
may be more susceptible to damage because very small
parametric changes could cause the device not to meet
published specifications.
Com 2 9
V
OUT
10
Sense 11
Gnd 2 12
16 –V
CC2
15 Sync*
14 +V
CC2
13 Enable
*Operation requires this pin be grounded or driven with TTL levels.
PACKAGE/ORDERING INFORMATION
PACKAGE
DRAWING
NUMBER
(1)
231
SPECIFIED
TEMPERATURE
RANGE
–25°C to +85°C
PACKAGE
MARKING
ORDERING
NUMBER
(2)
TRANSPORT
MEDIA
PRODUCT
ISO103
PACKAGE
24-Pin DIP
NOTES: (1) For detailed drawing and dimension table, please see end of data sheet, or Appendix C of Burr-Brown IC Data Book. (2) Models with a slash (/) are
available only in Tape and Reel in the quantities indicated (e.g., /2K5 indicates 2500 devices per reel). Ordering 2500 pieces of “ISO103/2K5” will get a single 2500-
piece Tape and Reel. For detailed Tape and Reel mechanical information, refer to Appendix B of Burr-Brown IC Data Book.
