LC6554H(64QFP) datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> LC6554H(64QFP)

LC6554H(64QFP): DescriptionMicrocontroller, 4-Bit, MROM, LC6500 CPU, 4.33MHz, CMOS, PQFP64; CategoryThe embedded processor and controller Microcontrollers and processors; File Size647KB，26 Pages; ManufacturerSANYO; Websitehttp://www.semic.sanyo.co.jp/english/index-e.html

Download Datasheet Parametric Compare View All

LC6554H(64QFP) Overview

Microcontroller, 4-Bit, MROM, LC6500 CPU, 4.33MHz, CMOS, PQFP64

LC6554H(64QFP) Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	SANYO
package instruction	QFP, QFP64,.8SQ,32
Reach Compliance Code	unknown
bit size	4
CPU series	LC6500
JESD-30 code	S-PQFP-G64
JESD-609 code	e0
Number of terminals	64
Maximum operating temperature	70 °C
Minimum operating temperature	-30 °C
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Encapsulate equivalent code	QFP64,.8SQ,32
Package shape	SQUARE
Package form	FLATPACK
power supply	5 V
Certification status	Not Qualified
RAM (bytes)	128
rom(word)	8192
ROM programmability	MROM
speed	4.33 MHz
Maximum slew rate	10 mA
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	OTHER
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	QUAD
Base Number Matches	1

Preview

Download Datasheet

View All

LC6554H(64QFP) Related Products

	LC6554H(64QFP)	LC6554H(64DIP)	LC6554D(64QFP)	LC6554D(64DIP)
Description	Microcontroller, 4-Bit, MROM, LC6500 CPU, 4.33MHz, CMOS, PQFP64	Microcontroller, 4-Bit, MROM, LC6500 CPU, 4.33MHz, CMOS, PDIP64	Microcontroller, 4-Bit, MROM, LC6500 CPU, 1.44MHz, CMOS, PQFP64	Microcontroller, 4-Bit, MROM, LC6500 CPU, 1.44MHz, CMOS, PDIP64
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible
Maker	SANYO	SANYO	SANYO	SANYO
package instruction	QFP, QFP64,.8SQ,32	SDIP, SDIP64,.75	QFP, QFP64,.8SQ,32	SDIP, SDIP64,.75
Reach Compliance Code	unknown	unknown	unknown	unknown
bit size	4	4	4	4
CPU series	LC6500	LC6500	LC6500	LC6500
JESD-30 code	S-PQFP-G64	R-PDIP-T64	S-PQFP-G64	R-PDIP-T64
JESD-609 code	e0	e0	e0	e0
Number of terminals	64	64	64	64
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C
Minimum operating temperature	-30 °C	-30 °C	-30 °C	-30 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	QFP	SDIP	QFP	SDIP
Encapsulate equivalent code	QFP64,.8SQ,32	SDIP64,.75	QFP64,.8SQ,32	SDIP64,.75
Package shape	SQUARE	RECTANGULAR	SQUARE	RECTANGULAR
Package form	FLATPACK	IN-LINE, SHRINK PITCH	FLATPACK	IN-LINE, SHRINK PITCH
power supply	5 V	5 V	5 V	5 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
RAM (bytes)	128	128	128	128
rom(word)	8192	8192	8192	8192
ROM programmability	MROM	MROM	MROM	MROM
speed	4.33 MHz	4.33 MHz	1.44 MHz	1.44 MHz
Maximum slew rate	10 mA	10 mA	10 mA	10 mA
Nominal supply voltage	5 V	5 V	5 V	5 V
surface mount	YES	NO	YES	NO
technology	CMOS	CMOS	CMOS	CMOS
Temperature level	OTHER	OTHER	OTHER	OTHER
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	GULL WING	THROUGH-HOLE	GULL WING	THROUGH-HOLE
Terminal pitch	0.8 mm	1.78 mm	0.8 mm	1.78 mm
Terminal location	QUAD	DUAL	QUAD	DUAL
