Small size, light weight.
Low coil power consumption.
PC board mounting.
Suitable for household electrical appliance, automation system, electronic equipment, instrument, meter,
telecommunication facilities and remote control facilities.
Ordering Information
JRC-19F 2C 3V 0.2
1
2
3
4
1 Part number:JRC-19F
2 Contact arrangement:2A:2A;2C:2C;
3 Coil rated Voltage(V):DC:3,4.5,5,6,12,24,48,
4 Coil power consumption:0.15:0.15W;0.2:0.2W;
0.36:0.36W;0.51:0.51W
Contact Data
Contact Arrangement
Contact Material
Contact Rating (resistive)
Max. Switching Power
Max. Switching Voltage
Contact Resistance or Voltage drop
Operation
Electrical
life
Mechanical
2A DPSTNO
f2C
DPDT(B-M)
Ag Ag Ni(Au clad)
2A/24VDC; 0.5A 1A/125VAC 30VDC ;
48W 60VA
24VDC 220VAC
Max. Switching Current:2A
50m
Item 3.12 of IEC255-7
5
10
Item 3.30 of IEC255-7
7
10
Item 3.31 of IEC255-7
Coil Parameter
Dash
numbers
003-150
004-150
005-150
006-150
012-150
024-150
003-200
004-200
005-200
006-200
012-200
024-200
003-360
004-360
005-360
006-360
012-360
024-360
003-510
004-510
005-510
006-510
012-510
024-510
048-510
Coil voltage
VDC
Rated
3
4.5
5
6
12
24
3
4.5
5
6
12
24
3
4.5
5
6
12
24
3
4.5
5
6
12
24
48
Max
3.9
5.9
6.5
7.8
15.6
31.2
3.9
5.9
6.5
7.8
15.6
31.2
3.9
5.9
6.5
7.8
15.6
31.2
3.9
5.9
6.5
7.8
15.6
31.2
62.4
Coil
resistance
±10%
60
135
166.7
240
960
3840
45
101
125
180
720
2880
25
56
70
100
400
1600
17.6
39.7
49
70.6
282.4
1129.4
4517.6
Pickup voltage
VDC(max)
(75%of rated
voltage )
2.25
3.15
3.50
4.20
8.40
18.0
2.25
3.15
3.50
4.20
8.40
18.0
2.25
3.15
3.50
4.20
8.40
18.0
2.25
3.15
3.50
4.20
8.40
18.0
36.0
release voltage
VDC(min)
(10% of rated
voltage)
0.3
0.45
0.5
0.6
1.2
2.4
0.3
0.45
0.5
0.6
1.2
2.4
0.3
0.45
0.5
0.6
1.2
2.4
0.3
0.45
0.5
0.6
1.2
2.4
4.8
Coil power
consumption
W
Operate
Time
ms
Release
Time
ms
0.15
6
5
0.20
6
5
0.36
6
5
0.51
6
5
CAUTION
:
1.The use of any coil voltage less than the rated coil voltage will compromise the operation of the relay.
2.Pickup and release voltage are for test purposes only and are not to be used as design criteria.
47
Solderability
Ambient Temperature
Relative Humidity
Mass
235x2 3x0.5s
-30~70
85% (at 40)
5g
IEC68-2-20 Test Ta method 1
IEC68-2-3Test Ca
Qualification inspection:
Perform the qualification test as specified in the table
of IEC255-19-1 and minimum sample size 24.
Safety approvals
Safety approval
Load
Dimensions (Unit: mm)
UL&CUR
1A/24VDC
T
ü
V
1A/125VAC;24DC
Mounting (Bottom views)
Dimensions
Wiring diagram
(Bottom views)
mm
0.25
0.3
0.6
1.0
1.2
4.0
5.08
7.62
10
12
21
inch
0.010
0.012
0.024
0.039
0.047
0.157
0.200
0.300
0.394
0.472
0.827
NOTES
1).Dimensions are in millimeter.
2).Inch equivalents are given for general information only.
Reference Data
