LTC1164-6MJ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> LTC1164-6MJ

LTC1164-6MJ: DescriptionLow Power 8th Order Pin Selectable Elliptic or Linear Phase Lowpass Filter; CategoryAnalog mixed-signal IC filter; File Size248KB，12 Pages; ManufacturerLinear ( ADI ); Websitehttp://www.analog.com/cn/index.html

Download Datasheet Parametric Compare View All

LTC1164-6MJ Overview

Low Power 8th Order Pin Selectable Elliptic or Linear Phase Lowpass Filter

LTC1164-6MJ Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Linear ( ADI )
Parts packaging code	DIP
package instruction	DIP, DIP14,.3
Contacts	14
Reach Compliance Code	unknow
ECCN code	EAR99
Active filter type	SWITCHED CAPACITOR FILTER
Center frequency or cutoff frequency maximum range	30 kHz
JESD-30 code	R-GDIP-T14
JESD-609 code	e0
length	19.43 mm
Maximum negative supply voltage (Vsup)	-8 V
Negative supply voltage minimum (Vsup)	-2.375 V
Nominal Negative Supply Voltage (Vsup)	-5 V
Number of functions	1
Number of terminals	14
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Order	8TH
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Encapsulate equivalent code	DIP14,.3
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
poles and zeros	8 AND 0
power supply	+-7.5 V
Certification status	Not Qualified
response	LOWPASS
Maximum seat height	6.604 mm
Maximum supply voltage (Vsup)	8 V
Minimum supply voltage (Vsup)	2.375 V
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	CMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
transfer characteristics	ELLIPTIC/BESSEL
width	7.62 mm

Preview

Download Datasheet

View All

LTC1164-6

Low Power 8th Order

Pin Selectable Elliptic or

Linear Phase Lowpass Filter

FEATURES

DESCRIPTIO

8th Order Pin Selectable Elliptic or Bessel Filter in a

14-Pin Package

4mA Supply Current with

±5V

Supplies

64dB Attenuation at 1.44 f

CUTOFF

(Elliptic Response)

CUTOFF

up to 30kHz (50:1 f

CLK

to f

CUTOFF

Ratio)

110µV

RMS

Wideband Noise with

±5V

Supplies

Operates at Single 5V Supply with 1V

RMS

Input Range

Operates up to

±8V

Supplies

TTL/CMOS Compatible Clock Input

No External Components

The LTC1164-6 is a monolithic 8th order elliptic lowpass

filter featuring clock-tunable cutoff frequency and low

power supply current. Low power operation is achieved

without compromising noise or distortion performance.

±5V

supplies the LTC1164-6 uses only 4mA supply

current while keeping wideband noise below 110µV

RMS

With a single 5V supply, the LTC1164-6 can provide up to

10kHz cutoff frequency and 80dB signal-to-noise ratio

while consuming only 2.5mA.

The LTC1164-6 provides an elliptic lowpass rolloff with

stopband attenuation of 64dB at 1.44 f

CUTOFF

and an f

CLK

to-f

CUTOFF

ratio of 100:1 (pin 10 to V

–

). For a ratio of 100:1,

CUTOFF

can be clock-tuned up to 10kHz. For a f

CLK

-to-

CUTOFF

ratio of 50:1 (pin 10 to V

), the LTC1164-6

provides an elliptic lowpass filter with f

CUTOFF

frequencies

up to 20kHz. When pin 10 is connected to ground, the

LTC1164-6 approximates an 8th order linear phase re-

sponse with 65dB attenuation at 4.5 f

– 3dB

and f

CLK

/ f

– 3dB

ratio of 160:1. The LTC1164-6 is pin compatible with the

LTC1064-1.

APPLICATI

Anti-Aliasing Filters

Battery-Operated Instruments

Telecommunication Filters

TYPICAL APPLICATI

10kHz Anti-Aliasing Elliptic Filter

LTC1164-6

1164-6 TA01

–8V

CLK = 1MHz

–8V

OUT

GAIN (dB)

–10

–20

–30

–40

–50

–60

–70

WIDEBAND NOISE = 115µV

RMS

NOTE: THE CONNECTION FROM PIN 7 TO PIN 14 SHOULD BE MADE

UNDER THE PACKAGE. THE POWER SUPPLIES SHOULD BE BYPASSED

BY A 0.1µF CAPACITOR AS CLOSE TO THE PACKAGE AS POSSIBLE.

–80

FREQUENCY (kHz)

100

1164-6 TA02

Frequency Response

LTC1164-6MJ Related Products

	LTC1164-6MJ	LTC1164-6CS	LTC1164-6M	LTC1164-6CJ	LTC1164-6C
Description	Low Power 8th Order Pin Selectable Elliptic or Linear Phase Lowpass Filter	Low Power 8th Order Pin Selectable Elliptic or Linear Phase Lowpass Filter	Low Power 8th Order Pin Selectable Elliptic or Linear Phase Lowpass Filter	Low Power 8th Order Pin Selectable Elliptic or Linear Phase Lowpass Filter	Low Power 8th Order Pin Selectable Elliptic or Linear Phase Lowpass Filter
Is it Rohs certified?	incompatible	incompatible	-	incompatible	-
Maker	Linear ( ADI )	Linear ( ADI )	-	Linear ( ADI )	-
Parts packaging code	DIP	SOIC	-	DIP	-
package instruction	DIP, DIP14,.3	SOP, SOP16,.4	-	DIP, DIP14,.3	-
Contacts	14	16	-	14	-
Reach Compliance Code	unknow	compli	-	compli	-
ECCN code	EAR99	EAR99	-	EAR99	-
Active filter type	SWITCHED CAPACITOR FILTER	SWITCHED CAPACITOR FILTER	-	SWITCHED CAPACITOR FILTER	-
Center frequency or cutoff frequency maximum range	30 kHz	30 kHz	-	30 kHz	-
JESD-30 code	R-GDIP-T14	R-PDSO-G16	-	R-GDIP-T14	-
JESD-609 code	e0	e0	-	e0	-
length	19.43 mm	10.3 mm	-	19.43 mm	-
Maximum negative supply voltage (Vsup)	-8 V	-8 V	-	-8 V	-
Negative supply voltage minimum (Vsup)	-2.375 V	-2.375 V	-	-2.375 V	-
Nominal Negative Supply Voltage (Vsup)	-5 V	-5 V	-	-5 V	-
Number of functions	1	1	-	1	-
Number of terminals	14	16	-	14	-
Maximum operating temperature	125 °C	85 °C	-	85 °C	-
Minimum operating temperature	-55 °C	-40 °C	-	-40 °C	-
Order	8TH	8TH	-	8TH	-
Package body material	CERAMIC, GLASS-SEALED	PLASTIC/EPOXY	-	CERAMIC, GLASS-SEALED	-
encapsulated code	DIP	SOP	-	DIP	-
Encapsulate equivalent code	DIP14,.3	SOP16,.4	-	DIP14,.3	-
Package shape	RECTANGULAR	RECTANGULAR	-	RECTANGULAR	-
Package form	IN-LINE	SMALL OUTLINE	-	IN-LINE	-
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	255	-	NOT SPECIFIED	-
poles and zeros	8 AND 0	8 AND 0	-	8 AND 0	-
power supply	+-7.5 V	+-7.5 V	-	+-7.5 V	-
Certification status	Not Qualified	Not Qualified	-	Not Qualified	-
response	LOWPASS	LOWPASS	-	LOWPASS	-
Maximum seat height	6.604 mm	2.65 mm	-	6.604 mm	-
Maximum supply voltage (Vsup)	8 V	8 V	-	8 V	-
Minimum supply voltage (Vsup)	2.375 V	2.375 V	-	2.375 V	-
Nominal supply voltage (Vsup)	5 V	5 V	-	5 V	-
surface mount	NO	YES	-	NO	-
technology	CMOS	CMOS	-	CMOS	-
Temperature level	MILITARY	INDUSTRIAL	-	INDUSTRIAL	-
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)	-
Terminal form	THROUGH-HOLE	GULL WING	-	THROUGH-HOLE	-
Terminal pitch	2.54 mm	1.27 mm	-	2.54 mm	-
Terminal location	DUAL	DUAL	-	DUAL	-
Maximum time at peak reflow temperature	NOT SPECIFIED	40	-	NOT SPECIFIED	-
transfer characteristics	ELLIPTIC/BESSEL	ELLIPTIC/BESSEL	-	ELLIPTIC/BESSEL	-
width	7.62 mm	7.5 mm	-	7.62 mm	-
